PREFACE

1-1 Conventions Used

WARNING
CAUTION
WARNING:
BURN
HAZARD
WARNING:
RISK OF
ELECTRIC
SHOCK

1-2 Glossary

AC: Alternating Current
DC: Direct Current
LCD: Liquid Crystal Display
LED: Light Emitting Diode
PC: Personal Computer
PV: Photovoltaic
SNMP: Simple Network Management Protocol

INTRODUCTION

2-1 Description

The Solar SP series is designed to have access to dual input source; one is AC source
from a grid, and the other is DC source from a solar array.
This series is a powerful all-in-one solution, not only delivering unsurpassed clean
true sine wave output power and combining this with a selectable multistage battery
charging current but also converting sunlight into clean energy. This series features
durable and continuous 24-hour operation. Consequently, it is applicable to any kind
of loads such as air conditioner, home appliances, consumer electronic and office
equipment.
The built-in 5-stage intelligent charger automatically charges any type of batteries
without the risk of overcharge. The compact and modular design makes utility
interactive installations easier and more cost effective. It is a high quality product that
Warnings identify conditions that could cause
personal injury or loss of life.
Cautions identify conditions that could cause damage
to the unit, other equipment or devices.
Keep away from unit because of burn hazard
resulting from high temperature during operation.
Risk of electric shock caused by energy stored in
capacitors. Capacitors take time to discharge after
cutting off all power sources.
