opti-solar SP2500 Junior Instruction Manual

Dc to ac 2500w inverter with built_in solar charger controller

Download this manual

Enlarged version

SOLAR INVERTER

DC TO AC 2500W INVERTER

WITH BUILT-IN SOLAR CHARGER CONTROLLER

DC12V or 24V to AC220V~240V Instruction Manual

Please read user manual before use.

INVERTER USEFUL APPLICATIONS

RUN NOTEBOOK COMPUTERS, RADIOS, TVS, VCRS,

LAMPS, FANS, FAX, DRILL, . . . . . . ETC.

Need help?

Do you have a question about the SP2500 Junior and is the answer not in the manual?

Page 1 SOLAR INVERTER DC TO AC 2500W INVERTER WITH BUILT-IN SOLAR CHARGER CONTROLLER DC12V or 24V to AC220V~240V Instruction Manual Please read user manual before use. INVERTER USEFUL APPLICATIONS RUN NOTEBOOK COMPUTERS, RADIOS, TVS, VCRS, LAMPS, FANS, FAX, DRILL, ..ETC.
Page 2 INVERTER SPECIFICATION INPUT VOLTAGE RANGE : DC 10~15V (12V) // DC 20~30V (24V) INPUT FULL LOAD CURRENT : 250A (12V) // 125A (24V) STANDBY INPUT CURRENT : <0.8A (12V) // <0.6A (24V) OUTPUT VOLTAGE (AC) : 220V~240V OUTPUT WAVEFORM : MODIFY SINEWAVE OUTPUT FREQUENCY : 50Hz or 60Hz CONTINUE OUTPUT POWER : 2500W PEAK OUTPUT POWER : 5000W...
Page 3 IF THE TOTAL WATTS OF ELECTRICAL APPLIANCES EXCEEDS SOLAR INVERTER THE OUTPUT CAPACITY OF INVERTER. OR AFTER OPERATING REMOTE CONTROL FOR A PERIOD OF TIME. IF THE TEMPERATURE OF THE TERMINA SWITCH INVERTER REACHES 60℃, THE INVERTER SHALL BE REDUCED (BLACK) REMOTE CONTROL...
Page 4 ※ USE INVERTER ※ USE SOLAR CHARGER CONTROLLER STEP1: DON’T REVERSE POLARITY OF DC SIDE. PLEASE SET DIP SWITCH TO CORRECT SET THE POWER SWITCH AT THE OFF LOCATION ACCORDING TO THE BATTERY. THE DC LOAD WHICH YOU CONNECTED CAN’T BE OVER THE RATING. REMOTE CONTROL AC OUTPUT...
