Summary of Contents for LEGRAND Radiant WWP20
- Page 1 Wi-Fi Smart Plug-in Tru-Universal Dimmer...
-
Page 2: Table Of Contents
table of contents before you start ............. 3 installation and setup ........... 4–7 getting to know your dimmer ........ 8–9 specifications ............10 regulatory information .......... 12–15 warranty ..............16 support..............17... -
Page 3: Before You Start
If the plug does not fit into the outlet, contact a qualified electrician to install the proper outlet. Do not change the plug in any way. Visit the Legrand website at www.legrand.us/radiant/smart-lighting/support installation videos or to learn more about your smart device. -
Page 4: Installation And Setup
installation & setup step one plug in the smart dimmer Insert the lamp to be controlled into the outlet on the smart plug-in dimmer. The smart dimmer up/down buttons can be reversed for use in outlets with the ground plug up: •... - Page 6 installation & setup step two test the smart plug-in dimmer NOTE: See page 8 for feature details. When the lamp is off, press the top button to turn your lamp on. Hold the bottom button to decrease the light level. Hold the top button to increase the light level.
- Page 7 & setup step three set up your system Download and launch the Smart Lights app by Legrand. The app is available on the App Store or on Google Play. Connect your smart plug-in dimmer to your home network by following the step by step instructions in the app.
-
Page 8: Getting To Know Your Dimmer
getting to know your dimmer Item Name Description Button Control Features • Top button: Press to turn the light on or Top Button double-tap to raise the dimming percentage to 100%. • Bottom button: Press to turn the light off. •... - Page 9 LED LOCATOR LIGHT EXPLANATIONS State of Explanation Color Light System is not ready. Solid Wait for blinking Amber Amber Device is ready for Blinking setup on your network Amber Device is connected to Solid your network and is White switched off Warns of an overload or Blinking short circuit while your...
-
Page 10: Specifications
300 W CFL/LED 100 W Legrand reserves the right to change specifications without notice. NOTE: The dimmer ships in forward phase mode to accommodate most load types. For loads that require reverse phase dimming, such as ELV loads, adjust the... -
Page 12: Regulatory Information
regulatory information FCC NOTICE This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. - Page 13 If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...
- Page 14 regulatory information This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm between the transmitter’s radiating structure(s) and the body of the user or nearby persons. NOTE: Any changes or modifications to this device that are not expressly approved by the manufacturer will void the warranty and the user’s authority to operate the equipment.
- Page 15 IC NOTICE This device complies with Industry Canada license-exempt RSS standards. Operation is subject to the following two conditions: (1) this device may not cause interference; and (2) this device must accept any interference, including interference that may cause undesired operation of the device. RF EXPOSURE STATEMENT This equipment meets the SAR evaluation limits given in RSS-102 Issue 5 requirements at the minimum separation distance of 15 mm to the human body.
-
Page 16: Warranty
1-877-833-3303. A dated sales receipt must be provided for all replacement requests (legible copies are acceptable). Additional warranty details are available at http://www.legrand.us under your device’s product page. -
Page 17: Support
IF YOU NEED HELP INSTALLING YOUR SMART PLUG-IN DIMMER, TALK TO OUR TECHNICAL SUPPORT TEAM: PHONE: 1-877-833-3303 8:00 a.m. to 8:00 p.m. EST (M-F). 8:00 a.m. to 5:00 p.m. EST (Sat) EMAIL: smartlighting@legrand.us CHAT: https://www.legrand.us/radiant/smart-lighting.aspx (Click on the icon to open a dialogue box) - Page 18 Legrand, North America 50 Boyd Avenue Syracuse, NY 13209 1-877-833-3303 www.legrand.us 11-12-2018 ©2018 Legrand All Rights Reserved 341219 Rev A 05/18...
