4. Use the HDMI or SDI cable to connect the transmitter to the camera.
SDI In
HDMI In
5. Use the HDMI or SDI cable to connect the receiver to the monitor or other
receiver end (as shown in the picture).
HDMI OUT
11
SDI OUT

Powering on and booting up

1. Power the transmitter and receiver with three ways as follows
a) Install the NP-F battery in the NP-F battery holder on the back of the transmitter.
b) Use the attached DC power adapter
c) Use a V-mount battery (USB-D to DC power cable is needed in this case).
d) Use a power bank (5V/2A) with Type-C cable
2. Booting up the transmitter and receiver requires about 30 seconds. Wireless
connection between transmitter and receiver will be established automatically
after power up.
