User Operation Instructions

Thank you for choosing CVW's professional wireless high-definition video
and audio transmission product. Before using this product, please carefully
read the following reminders:
* Avoid exposing this product to direct sunlight or dusty places for a long period of time
* This product must be used within its temperature and humidity range
* Do not operate this product when it is vibrating or in a strong magnetic field
* Do not put electroconductive materials into this product's vents
* Please do not disassemble this product without guidance from our professional staff
* Before booting up this product, confirm that the adapter's input voltage is AC110V-220V
and that the output voltage flow meets this product's specification requirements
* Before plugging in the battery, confirm that the battery's voltage meets this product's
specification requirements

About This Manual

This manual provides a detailed introduction to this product's specifications and
instructions, operation instructions, reminders, and troubleshooting. Before using
this product, please carefully read this manual. If you have any questions or difficulties
while using this product, please promptly contact us or our distributor.

Product Introduction

This product is a wireless video transmission kit which operates in 5G band that
delivers a video resolution up to 1080P60Hz and is widely applied in field such as
live streaming, film and TV production, etc.
01

Connectivity diagram

This product includes a transmitter and a receiver. The transmitter supports HDMI input
or SDI input and output. The receiver supports simultaneous output of 1 HDMI circuit
and 2 SDI circuits. The figure below is the connectivity diagram you may refer to.
Point-to-point mode
Support HDMI/SDI signal input and output
DSLR Camera
Transmitter
Camera
RSTP streaming mode
Support HDMI/SDI signal input and output (Support up to 4 mobile devices)
Transmitter Phone
Monitor
Receiver
00:00:00
Switcher
Tablet
02
