Product Interface Introduction
Transmitter 7103
TX:7103
A
B
C
D
E
F
L
05
TX
G
H
USB
I
LOOP OUT
J
K
Transmitter 7103 Interface Instructions
Serial
Number
A
SMA jacks for connectors
B
Low Battery Indicator
C
Power Button
OLED Screen
D
E
CH Button
F
MODE Button
G
HDMI In
H
DC In
I
Type-C USB Port
J
SDI Loop Out
K
SDI In
NP-F Battery Slot
L
Explanation
