Product Installation Operation Instructions

1. Please install the antennas on the receiver and transmitter via the antenna port.
There should be a 90° angle between each antenna (the optimal installation method)
as shown in the picture.
90
2. Install NP-F batteries in both the transmitter and the receiver
09
3. Install the transmitter and receiver on
the camera using the 1/4 screw hole on
the bottom or the L-shaped mount
Battery
10
