SHENZHEN CRYSTAL VIDEO TECHNOLOGY CO.,LTD
ADD: F12, F518 Idea Land, Baoyuan Road, Baoan Central Area,Shenzhen, China
Post code：518102
Fax: +86-755-29188427
Tel: +86-755-27750518-6652
www.cv-hd.com
E-mail: Sales@cv-hd.com
E-mail: Marketing@cv-hd.com
Swift800 Pro
SDI & HDMI Wireless Video
USER MANUAL
This user manual applies to:
Transmitter: 7103
Receiver: 3103
Version: 1.0
2020.05.26
Advertisement
Table of Contents
Related Manuals for Crystal Video Swift800 Pro
Summary of Contents for Crystal Video Swift800 Pro
- Page 1 Swift800 Pro SDI & HDMI Wireless Video USER MANUAL SHENZHEN CRYSTAL VIDEO TECHNOLOGY CO.,LTD ADD: F12, F518 Idea Land, Baoyuan Road, Baoan Central Area,Shenzhen, China This user manual applies to: Post code：518102 Fax: +86-755-29188427 Transmitter: 7103 Tel: +86-755-27750518-6652 www.cv-hd.com Receiver: 3103 E-mail: Sales@cv-hd.com...
- Page 2 Optimal range between transmitter and receiver is between 1 meter and 30 meters with in line of sight indoor...
-
Page 3: Table Of Contents
CONTENTS User Operation Instructions About This Manual Product Introduction Connectivity diagram Packing List Product Interface Introduction Transmitter Interface Introduction Receiver Interface Introduction Product Installation Operation Instructions Powering on and booting up OLED Screen Button Function Instructions How to Use the App Product Specifications Reminders Troubleshooting... -
Page 4: User Operation Instructions
User Operation Instructions Connectivity diagram This product includes a transmitter and a receiver. The transmitter supports HDMI input Thank you for choosing CVW’s professional wireless high-definition video or SDI input and output. The receiver supports simultaneous output of 1 HDMI circuit and audio transmission product. - Page 5 Product Highlights Packing List Deliver quality and low latency video transmission The standard parts are listed below. Support HD-SDI & 3G-SDI input/output and full-HD input/output via HDMI with a resolution up to 1080P60Hz. The built-in H.264 codec delivers smooth video with latency as low as 70ms.
-
Page 6: Product Interface Introduction
Product Interface Introduction Transmitter 7103 Transmitter 7103 Interface Instructions TX:7103 Serial Explanation Number SMA jacks for connectors Low Battery Indicator Power Button OLED Screen CH Button MODE Button HDMI In DC In Type-C USB Port SDI Loop Out SDI In NP-F Battery Slot LOOP OUT... -
Page 7: Receiver Interface Introduction
Receiver 3103 Interface Instructions: RX:3103 Receiver 3103 Interface Introduction Serial Explanation Number SMA jacks for connectors Low Battery Indicator Power Button OLED Screen CH Button MODE Button HDMI Out DC In Type-C USB Port SDI Out SDI Out NP-F Battery Slot... -
Page 8: Product Installation Operation Instructions
Product Installation Operation Instructions 1. Please install the antennas on the receiver and transmitter via the antenna port. There should be a 90° angle between each antenna (the optimal installation method) as shown in the picture. Battery 3. Install the transmitter and receiver on the camera using the 1/4 screw hole on the bottom or the L-shaped mount 2. -
Page 9: Powering On And Booting Up
Powering on and booting up 4. Use the HDMI or SDI cable to connect the transmitter to the camera. 1. Power the transmitter and receiver with three ways as follows a) Install the NP-F battery in the NP-F battery holder on the back of the transmitter. b) Use the attached DC power adapter c) Use a V-mount battery (USB-D to DC power cable is needed in this case). -
Page 10: Oled Screen
OLED Screen SSID Model: 7103+3013 930333 Fan Status Video Signal NO VIDEO Battery Charge Network Signal Operating Frequency CH 1 Video Signal NO VIDEO Working Mode RTSP Operating Frequency CH 1 Battery Charge: (Displayed only when using Sony NP-F batteries to supply power) Fan Status: (When the fan is on, displays rotating fan blades;... -
Page 11: Button Function Instructions
Button Function Instructions Mode Switching 1. Switching operation must be applied on both the transmitter and receiver. CH Button 2. Factory mode is point-to-point mode Press this button to switch channels. 3. Long press the transmitter and receiver Mode button for 3 seconds for mode switching, when switching from point-to-point mode to RTSP streaming mode, "RTSP"... -
Page 12: How To Use The App
Product Specifications How to Use the App Item TX: 7103 RX: 3103 1. Download the App Frequency 5.10~5.80 (GHz) App download method can be obtained at www.cv-hd.com 1080p60/59.94 , 1080p50 1080p30/29.97 1080p25 1080p24/23.98 2. Install App Video Format 1080psf24/23.98(SDI In) 1080i60/59.94, 1080i50, 720p60/59.94 , 720p50, 480P, 576P, 480i, 576i 3. -
Page 13: Reminders
Reminders Cable Connection a) First connect the video signal cord, and then turn on the power supply. Installing Height and Interval Distance b) During normal usage, avoid hot swapping the video signal cords. 1. In wide-open and unobstructed conditions, and when using the most optimal installation methods for antennas, this product’s transmission distance can reach Product and Antenna Installation 250 meters. -
Page 14: Troubleshooting
Troubleshooting 3. The receiver and broadcast station or monitor do not have a screen output. 1. The transmitter and receiver cannot establish a connection. a) Check whether the product’s antenna has been installed correctly. a) Check whether the power adapter or battery input comply with this product’s specification requirements.
