How to Use the App

1. Download the App
App download method can be obtained at www.cv-hd.com
2. Install App
3. Switch the product to RTSP working mode
4. Open the app, click the app's linked icon, and choose the corresponding SSID
number. The default SSID uses CVW's format heading (with one touch of the
transmitter's power button, the OLED display screen displays the SSID's last six
digits). Input password: 12345678 to connect.
5. After successfully connecting, an image displays on the screen, and the menu can
be used to choose the corresponding function load.
17

Product Specifications

Item TX: 7103
Frequency 5.10~5.80 (GHz)
1080p60/59.94 , 1080p50 1080p30/29.97 1080p25 1080p24/23.98
Video Format 1080psf24/23.98(SDI In) 1080i60/59.94, 1080i50,
720p60/59.94 , 720p50, 480P, 576P, 480i, 576i
Audio Format PCM
HDMI Protocol HDMI 1.3, HDMI 1.4
System Latency 70ms
Transmission range 250m (Line of sight)
Antenna Mode 2T2R External
DC-IN, SDI-IN, SDI-LOOP OUT,
HDMI-IN, Type-C, USB,
Interfaces
Sony NP-F970 Battery Interface
SMA Antenna port x 2
Button 1. POWER; 2. CH; 3. MODE
1. DC (7V-36V)
Operating
2. Battery Plate: (Sony NP-F Series)
voltage
3. Power bank (Type-C 5V2A)
Product Dimensions 115 x 70 x 21 (Unit: mm, Battery plate not included)
Operating T emperature -10~45°C
Storage T emperature -40- 80°C
Product Certification FCC, CE
Mechanical interface 1/4 inch nut on the bottom, L-shaped mount
RX: 3103
, , ,
DC-IN, SDI-OUT x 2, HDMI-OUT,
Type-C, USB,
Sony NP-F970 Battery Interface
SMA Antenna port x 2
,
