Universal VESA Adapter Bracket Kit
Instruction Manual
SKU: MOUNT-UVM01
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-uvm01
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
309-278-5303
Chat live with an agent!

Advertisement

loading
Need help?

Need help?

Do you have a question about the MOUNT-UVM01 and is the answer not in the manual?

Questions and answers

Related Manuals for Vivo MOUNT-UVM01

Summary of Contents for Vivo MOUNT-UVM01

  • Page 1 Universal VESA Adapter Bracket Kit Instruction Manual SKU: MOUNT-UVM01 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-uvm01 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...

  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.

  • Page 3: Assembly Steps

    ASSEMBLY STEPS PART A: Preparation STEP 1 Place monitor face down on a flat surface with bottom of monitor facing towards you. Install power, video and other cables to monitor to assist in determining needed clearance. STEP 2 Align bottom of one lower vertical bracket (B) with bottom edge of monitor. Locate hangers closest to centerline of monitor, then mark the next hanger above center with a pencil.
  • Page 4 STEP 3 Hold the main plate (G) to center of back of monitor. Locate and mark entire region on each side that does not overlap with any buttons or ports. NOTE: Please be sure to also check for buttons on the bottom edge of the monitor! ✓...
  • Page 5 STEP 4 Hold an adhesive pad (S) to the bottom edge of the monitor and trim length of pad to match monitor. Trim remaining pads to the same length, and apply to inner faces of upper and lower support brackets (C, D) towards the front. C + D PART B: Lower Bracket Assembly STEP 1...
  • Page 6 STEP 1 (Continued) Move the main plate (G) up or down to avoid ports as necessary. Ports STEP 2 Secure the main plate to the brackets using M5x15mm screws (N). If main plate is located at the highest position, instead use M6x16mm carriage bolts (O) with M5 nuts (P) and tighten with the wrench (R).
  • Page 7 PART C: Upper Bracket Assembly STEP 1 Place lip of one lower support bracket (D) under monitor edge where it will be installed. Align lower vertical bracket (B) with first available hole in support bracket above monitor and insert M5x8mm flat head screw (M). Attach other lower support bracket at same location to opposite vertical bracket.
  • Page 8 STEP 2 Attach upper support brackets (C) to upper vertical brackets (A) using M5x8mm flat head screws (M) at same hole positions as lower support brackets. Do not yet tighten screws. PART D: Assemble Brackets to Monitor STEP 1 Partially slide upper vertical brackets (A) into lower vertical brackets (B).
  • Page 9 STEP 2 Position assembly on the back of the monitor. Slide upper brackets down, making sure the upper and lower support brackets are fully engaged with the monitor. Insert M5x6mm screws (L) into back of vertical brackets and tighten to secure brackets. All support bracket lips under monitor edge.
  • Page 10 STEP 3 (Continued) STEP 4 Making sure upper and lower support brackets are correctly aligned and holding monitor, tighten M5x8 flat head screws (M) with a Phillips screwdriver. Tighten screws M Tighten screws M...
  • Page 11 PART E: Attach Monitor to Monitor Mount STEP 1 Attach VESA plate (H) to monitor/TV mount using M4x12 screws (J) with washers (K). STEP 2 Carefully slide monitor with assembled VESA adapter onto VESA plate and secure with the 10mm thumbscrew (I). Route cables through plate openings for cable management if desired.
  • Page 12 - 92% within < 3hr : < 15 M www.vivo-us.com AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
