Baileigh STS-16120CNC Operator's Manual

Sliding
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATOR'S
MANUAL
SLIDING TABLE SAW
MODEL: STS-16120CNC
Baileigh Industrial, Inc.
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: 920.684.4990
Fax: 920.684.3944
sales@baileighindustrial.com
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC.
IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss
caused by an omission or error in this Operator's Manual, resulting from accident, negligence, or other occurence.
Rev. 01/2018
© 2018 Baileigh Industrial, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STS-16120CNC and is the answer not in the manual?

Questions and answers

Related Manuals for Baileigh STS-16120CNC

Summary of Contents for Baileigh STS-16120CNC

  • Page 1 REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC. IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurence.

  • Page 2: Table Of Contents

    Table of Contents M-10-e CONTROLLER INTRODUCTION ..............23 Specifications: ......................23 ABS/REL Definition ....................24 Front Panel and LCD Display ..................24 Load Datum Values (Only In ABS Mode) ..............26 Select Counting Direction (+/-) .................. 30 Set Device Resolution ....................32 Enable and Disable Specified Parameter ..............
  • Page 3 Display and Operation of Each Function of Home Page Numerical value Positioning Operation Ex: If main saw blade’s present value is 0.0 and you want to rise main saw blade to 50.0, the operating way as follows: Step 1: Push key to make Numeric Keypad show up.
  • Page 4 Micro-Motion Positioning Operation Ex: If main saw blade’s present value is 0.0 and you want to rise the main saw blade to 30.0, the operating way as follows: Step: Push key until key shows present value 30.0. Note: When micro-motion positioning movement is used, key won't show any target value.
  • Page 5 Display of Motor RPM Motor rpm is shown on the upper right corner of the home page. Note: This system's RPM is only for display without setting function. If rpm needs to be changed, it is changed by changing the belt position.
  • Page 6 Function Page Operation Processing Editing Operation The processing edition is a temporarily processing group provided by this system without memory function. When power is off, the processing group will be cleared automatically. If you want to memorize the input group, please use program page operation. Ex: If you want to cut wooden board, please input the desired group.
  • Page 7 Step 3: Input 35, push key to finish input. The value input way of the tilting angle and rip fence is the same. Step 4: Push key to save and lock system. Step 5: Push key to release lock. Push key to select processing group.
  • Page 8 Step 6: Push key to confirm all selected groups. After confirmation, system will return to home page automatically. Note: When this system wants to select group key , you must first release lock and then can select. If lock is not released, group key cannot be selected.
  • Page 9 Dimension Calculation Operation When dimension calculation function is used, the wooden board’s height, angle and distance must be input. The height and angle as shown on A and B of the right drawing are the necessarily input numerical values. The calculating way as follows: Input A, B and C to calculate D.
  • Page 10 Step 3: Push key to save the calculated result onto the target value of home page. Or push key to return to home page but the calculated result will be cancelled and won't be saved into target value. Step 4: Push key to start action.
  • Page 11 Program Page Operation The page is a memory group function provided by this system. A~T stands for a code and each code can memorize 5 groups, so total 100 groups. Ex: If you want to memorize one cutting size on A area and select that group cutting size, the operating way as follows: Step 1: Push key on home page to enter...
  • Page 12 Step 3: Push to number that group After selection, ASCII-KEY is shown up. Step 4: Input the number to be classified, push to finish input. Note: The ASCII-KEY of this system can input signs. The following is explanation of each key. : Sign shift key.
  • Page 13 Step 6: Push key to release lock. Push key to select group and then push key to confirm the selected group. After confirmation, the system will return to home page automatically. Step 7: After returning to home page, the numerical value will be saved into the target value automatically.
  • Page 14 Operation of setting page Operation of saw Blade Specification The function is for changing saw blade specification. Ex: If the present saw blade is 12” and you want to change it into 14”, the operating way as follows: Step 1: Push key on home page to enter saw blade specification page.
  • Page 15 Step 3: Push key to save, The setting is completed. Note: After the specification of main saw blade is changed, the saw blade’s height fence’s position, saw blade’s UP/DOWN +/- limit parameter will be meet the specification parameter of the present main saw blade.
  • Page 16 Operation of Fence Size The function is for setting rip fence size. Ex: If the present rip fence’s size is set at 52, 92 but actually measured size is 51.9, 92 and you want to change the setting size, the operating way as follows: Step 1: Push key on home page, Push...
  • Page 17 Operation of Position Correction The function is for setting the present value of each shaft’s position. Ex: If the main saw blade shown on the page is 5 degree but actual angle is 0 degree, the operating way as follows: Step 1: Push key on home page.
  • Page 18 Operation of Unit Change The function is for changing unit. Ex: The pre-setting unit of this system is mm and you want to change it into inch, the operating way as follows: Step: Push key on home page. Push key to enter unit change page. Push key to change unit.
  • Page 19 Operation of System Page Operation of UP/DOWN Parameter The function is for setting each parameter of main saw blade UP/DOWN such as +/- limit value, UP/DOWN parameter, deceleration distance. Ex: If parameter of main saw blade UP/DOWN is 7900 and you want to change it into 7950, the operating way as follows: Step 1: Push key on home page to enter...
  • Page 20 Step 3: Push key for confirmation. Step 4: Push key to edit parameter value. Step 5: Input parameter 7950. Push key to finish input.
  • Page 21 Step 6: Push key to save. The setting is completed. Note: The parameter changing way of tilting parameter, rip fence, main saw blade tilting rotary center correction parameter is the same as the Up/Down Parameter change. Introduction to Tilting Parameter Page + Limit value.
  • Page 22 Introduction to Rip Fence Parameter Page 1. + Limit value. 2. - Limit value. 3. Parameter value. 4. Deceleration distance. 5. Backlash value (Clear rip fence backlash setting value) 6. Safety area (protection value at saw blade cutting angle) Introduction to Rotary Center correction Page 45°...
  • Page 23 Introduction to Machine Data Page 1. Model. 2. Date of production. 3. System password. 4. Reconfirm the system password. 5. Observing password. 6. Observing password reconfirmed. 7. Timer of motor braked. 8. Software version. 9. PLC error message. Note: If above setting values are freely changed, it results in reducing machine’s accuracy and even seriously machine damaging.
  • Page 24 Operation of Changing System Password The following is the operating sequence of changing system password. When you enter the machine data page, please refer to steps 1 ~ 3 of chapter 4-6-1. Step 1: Push key on system operation page to enter machine data page. Push system password to let the Numeric Keypad show up.

  • Page 25: M-10-E Controller Introduction

    M-10-e CONTROLLER INTRODUCTION  Magnetic measuring  Programmable coefficient setting  The battery life: 1 year  Low battery alarm  Multifunction LCD display  Parameters stored in permanent memory  Resolution 5μm、10μm、100μm、1mm  Correct zero point  Max. gap: 2.5mm ...

  • Page 26: Abs/Rel Definition

    ABS/REL Definition ABS (absolute) REL (incremental) ⊗ ⊗ Zero point: 0 mm ⊗ Zero point: 0 mm ⊗ ⊗ ⊗ 1.000mm 1.000mm 1.000mm 2.000mm 2.000mm 4.000mm Front Panel and LCD Display...

  • Page 28: Load Datum Values (Only In Abs Mode)

    Load Datum Values (Only In ABS Mode) A. Description...
  • Page 30 B. Load Datum...
  • Page 31 C. Troubleshooting...

  • Page 32: Select Counting Direction (+/-)

    Select Counting Direction (+/-)

  • Page 34: Set Device Resolution

    Set Device Resolution...

  • Page 36: Enable And Disable Specified Parameter

    Enable and Disable Specified Parameter...

  • Page 39: Appendix A - Parameter

    Appendix A - Parameter Parameter Display Description Default Remarks Origin Load datum value Select counting direction(±) dir - - Off SETS Set tool diameter ANGULAR Enter semi diameter value SCALING Diameter / semi diameter Lin Corr Linear correction 1.00000 SETUP Fine adjustment distance Enable/disable Parameter 0000...

  • Page 40: Parameter Setting

    Parameter Setting...

  • Page 41: Appendix B - Calibration

    Appendix B - Calibration A. For better accuracy, calibrate for the first time installation, or if the slider has been reinstalled. Gap: 1~2.5mm (Recommended: 1mm) Gap about 1mm...

  • Page 43: Troubleshooting

    B. Troubleshooting...

  • Page 45: Maintenance

    MAINTENANCE WARNING: Make sure the electrical disconnect is OFF before working on the machine. Maintenance should be performed on a regular basis following proper safety precautions. This table saw requires very little maintenance other than minor lubrication and cleaning. The following sections detail what will need to be done in order to assure continued operation of your saw.

  • Page 46: Lubrication

    Lubrication The table saw has sealed lubricated bearings in the motor housing and the arbor assembly, they will not require any additional lubrication. Use a wire brush to clean off the worm gears and trunnions and apply a white lithium grease to keep them lubricated. It is essential to clean components before lubricating them because dust and chips build up on lubricated components and make them hard to move.

  • Page 47: Troubleshooting

    TROUBLESHOOTING WARNING: Disconnect machine from the power source before attempting any troubleshooting. Table Troubleshooting TROUBLE CAUSE GUIDE 1. Check if power or voltage is Input correct voltage. normal. No Display 2. If power is correct, controller is Send it to the factory for repair. damaged.

  • Page 48: Touch Screen Troubleshooting

    Touch Screen Troubleshooting TROUBLE ACTION Error dimension statistics Input correct numerical value Safety bar is touched.Please release it and Rip fence paused push START key again. Push START key until rip fence reaches the Rip fence moved into safety area position of the input value.
  • Page 49 TROUBLE ACTION Check if the encoder wiring is correct and the Rip fence did not move after START motor runs normally. Rip fence did not move to the target Act as No. 14. position 1. Start the machine again to see if the trouble can be solved.

  • Page 50: Electrical Schematic - 1

    ELECTRICAL SCHEMATIC - 1...

  • Page 51: Electrical Schematic - 2

    ELECTRICAL SCHEMATIC - 2...

  • Page 52: Electrical Schematic - 3

    ELECTRICAL SCHEMATIC - 3...
  • Page 53 NOTES...
  • Page 54 NOTES...
  • Page 55 NOTES...
  • Page 56 , WI 54220 UFEK RIVE ANITOWOC : 920. 684. 4990 F : 920. 684. 3944 HONE BAILEIGHINDUSTRIAL BAILEIGH INDUSTRIAL, INC. 1455 S. C , CA 91761 AMPUS VENUE NTARIO : 920. 684. 4990 F : 920. 684. 3944 HONE BAILEIGH INDUSTRIAL LTD. U...
