Summary of Contents for Code Blue CB RT
- Page 1 CB RT Installation | Confi guration | Operation | Troubleshooting Administrator Guide 800.205.7186 www.codeblue.com •...
- Page 2 OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF. Code Blue Corporation reserves the right to make any modifications to this guide or the information contained herein at any time without notice. The software described herein may also be governed by the terms of a separate user license agreement.
-
Page 3: Table Of Contents
3 Getting Started................5 4 Spare Parts..................6 5 Technical Features................. 7 6 Exploded View................8 7 Power Requirements..............10 8 CB RT Installation Instructions............13 9 Overhead Camera Mount Installation Instructions.....15 10 Standard Wiring................17 11 PoE Wiring..................18 12 Serial Number Location..............19 13 Line Power Installation Instructions........... -
Page 4: Introduction
• IP and analog phones • Overhead Camera Mount This guide contains all of the CB RT tower information. This manual contains a general overview of the Code Blue CB RT Tower options and its application, installation and wiring. CB RT... -
Page 5: Getting Started
1. EIA/TIA, ANSI, CSA and BICSI cabling or similar standards shall be adhered to for proper operation of Code Blue communication devices connected to copper or fiber infrastructures. Communications cable and electrical cable in the same conduit is not an acceptable instal- lation and shall not be supported. -
Page 6: Spare Parts
CB RT Administrator Guide 4 Spare Parts CB RT Part Part Number LED Strobe Light 40159 LED Faceplate Light 40196 Faceplate Screws 41544 (6 pack) Access Door Screws 41545 (2 pack) Analog Surge Suppressor 41471 IP Surge Suppressor 41421 Code Blue... -
Page 7: Technical Features
CB RT Administrator Guide 5 Technical Features Specifications • Height: 9’ (289.56 cm) • Weight: 225 lbs. (102.06 kg) • Width: 10” (21.90 cm) • Depth: 8” (21.90 cm) • Material & thickness: 0.1875” steel • Access door: 15.88” x 7.88” (40.34 x 20.02 cm) Power •... -
Page 8: Exploded View
CB RT Administrator Guide 6 CB RT Exploded View ITEM # DESCRIPTION Tower Assy Painted LED Blue Beacon Strobe Standard / Custom Graphic DIN Rail Assy 114” Harness Connector LED Faceplate Light Model/Serial Number Graphic Inspected and Tested Graphic Access Door... - Page 9 CB RT Administrator Guide 10.00 8.00 4.26 2.13 45° TYP 6.00 4.00 105.50 Bottom View BASE PLATE DETAIL SCALE 1:8 113.51 16.00 11.06 8.00 SIDE VIEW BACK VIEW Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 9 of 27 GU-163-A •...
-
Page 10: Power Requirements
CB RT Administrator Guide 7 Power Requirements (2020) (The following power requirements include the CB RT and also ALL OTHER Code Blue units.) Component Specs Faceplates Voltage Max Current Max Watts Norm Current Norm Watts KWHrs High V IA4100 24V AC 0.40... - Page 11 0.22 S-1050 LED Strobe w/ Photocell 24V AC 2.80 67.20 0.22 5.28 0.13 12V DC 2.68 32.16 0.38 4.56 0.11 CB RT 24V DC 2.68 64.32 0.38 9.12 0.22 LED Light Bar 24V AC 0.04 0.96 0.04 0.96 0.02 12V DC 0.04...
- Page 12 ® CB 4-u w/ NightCharge 0.22 120V AC 0.13 0.11 CB RT 0.22 0.02 0.01 0.02 Administrator Guide 1.21 Power Requirements continued Models With IP5000 Faceplate Voltage Current Watts KWHrs CB 1-e 24V AC 0.33 7.92 0.19 12V DC 0.43 5.16...
-
Page 13: Cb Rt Installation Instructions
CB RT Administrator Guide 8 CB RT Installation Instructions 1.0 FOUNDATION - ANCHOR BOLT INSTALLATION INSTRUCTIONS 1.1 Conduit – Electrical and communication line conduit should be run through the center of the foun dation hole with a maximum combined diameter of three inches. A minimum of four inches and a maximum of six inches of conduit is required above the finished grade level. - Page 14 CB RT Administrator Guide 2.0 SET THE UNIT 2.1 Screw one set of nuts and washers onto the anchor bolts – After the foundation has set, screw one set of nuts followed by one set of washers onto the anchor bolts. Set the nuts so the lowest washer is about 2½...
-
Page 15: Overhead Camera Mount Installation Instructions
CB RT Administrator Guide 9 Overhead Camera Mount Installation Instructions TOOLS REQUIRED Ladder Access Panel Security Bit Wrench INSTALLING THE OVERHEAD CAMERA MOUNT The camera mount will come with a gasket already mounted to the bracket on the arm. Place the bracket over the mounting holes and insert the four 3/8-16 X 1 stainless bolts. - Page 16 CB RT Administrator Guide CB RT WITH OVERHEAD CAMERA MOUNT 51.38 1.00 2.50 DESCRIPTION TOLERANCES UNLESS OTHERWISE SPECIFIED ANGLES ± 1° STRUCTURAL MACHINING NEXT LEVEL REV NO. ±.12 ±.030 THIRD ANGLE PROJECTION DRAWING NO. Please contact Customer Service with any questions or concerns.
-
Page 17: Standard Wiring
CB RT Administrator Guide 10 CB RT Standard Wiring Beacon Strobe Faceplate LED Bar For Incoming Power 24V AC/DC or 100-277V AC For High Voltage leave connected. To Ground IP5000 For Low Voltage RJ45/RJ11 disconnect and apply incoming power. Incoming... -
Page 18: Poe Wiring
CB RT Administrator Guide 11 PoE Installation Instructions Beacon Strobe Faceplate LED Bar For Incoming Power Incoming POE IP5000 Ground Code Blue 259 Hedcor Street Holland, MI 49423 USA 800.205.7186 www.codeblue.com page 18 of 27 GU-163-A • • • •... -
Page 19: Serial Number Location
CB RT Administrator Guide 12 Locating Unit Serial Numbers Remove the access plate cover with the special security bit. The serial number will be listed on the manufacturer’s label located on the backside of the access plate cover (1). Code Blue... -
Page 20: Line Power Installation Instructions
CB RT Administrator Guide 13 Line Power Installation Instructions IMPORTANT: All wiring shall comply with national and local codes governing this installation. It is the responsibility of the installer to ensure these conditions are complied with. 1.0 SUPPLY WIRING 1.1 Pulling the power wires – Wire should be a minimum of 14 AWG and be pulled into the unit, leaving a minimum of two feet of wire from the opening of the conduit. -
Page 21: 1000/S-1050 Installation Instructions
CB RT Administrator Guide 14 S-1000 & S-1050 Installation Instructions NOTE: Instructions pertain to Model S-1000 LED Beacon/Strobe and Model S-1050 LED Beacon/Strobe only POSITIVE (12-24V DC or AC) BLACK COMMON (GROUND) YELLOW (FLASH MODE) DRY CONTACT CLOSED = "ON"... - Page 22 CB RT Administrator Guide PROGRAMMING PRIMARY & SECONDARY MODES 1. Remove power from unit. 2. Short the Yellow wires together. 3. Restore power to the unit and wait until the unit begins to flash. Once the unit begins to flash, remove the short.
-
Page 23: Software Configuration
A sophisticated emergency management platform for your blue light phone network, ToolVox offers unique real-time monitoring and provisioning options for emergency phones and public address speakers, effectively acting as a hub for connecting Help Points and other Code Blue devices. Us- ® ing our proprietary incident response software, Blue Alert MNS and EMS, you can send alerts via ®... -
Page 24: Maintenance
Verify bottom of bollards are at least 1/2 inch above footing and free of obstructions (Only applies to CB 1, CB 5, CB 9 and CB RT units) Apply automotive paint sealant to unit exterior for protecting finish against environmental pollutants (Suggested... - Page 25 Administrator Guide UNIT SURFACE MAINTENANCE The painted and stainless steel Code Blue models require periodic care to sustain their aesthetic appearance. Units located outdoors are vulnerable to harsh environmental conditions, including UV rays, acid rain, diesel fumes and airborn iron particles (i.e., dust) which over time may cause unit discoloring.
-
Page 26: Warranty
Administrator Guide 17 Warranty Code Blue Corporation provides a limited warranty on this product. Refer to your sales agreement to establish the terms. In addition, Code Blue’s standard warranty language, as well as information regarding support for this product while under warranty, is available at www.codeblue.com/support. -
Page 27: Download Information
CB RT Administrator Guide Download Information 18 Download Information Code Blue now has a centralized location where you can find installation, setup, information, configuration and operation instructions. ® 1. Centry Administrator Guide: www.codeblue.com/resources/guides 2. CB 1 Series Administrator Guide: www.codeblue.com/resources/guides 3.
