IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE
NOTICE
It is the Purchaser's/Owner's obligation:
1. To disclose and post all Rules & Regulations, Danger, Warning and Caution
labels affi xed on the machine to their customers/users.
2. Equipment to be installed by TFI Authorized Dealer or a service
company approved by TFI.
3. Provide trained personnel, supervision and correct usage of the equipment.
4. Provide scheduled inspection, maintenance & repairs and must be performed
by TFI Authorized Dealer or a service company approved by TFI.
5. Must use only genuine TFI replacement parts.
6.
Machine must be anchored to a solid and level surface.
Maintenance & Assembly Instructions
BA-706
MID ROW
OWNER'S MANUAL
BA-706_REV0
Revision Date: 5-21-2018
Advertisement
Table of Contents
Related Manuals for TuffStuff BIO-ARC MID ROW BA-706
Summary of Contents for TuffStuff BIO-ARC MID ROW BA-706
- Page 1 Maintenance & Assembly Instructions IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE NOTICE It is the Purchaser’s/Owner’s obligation: 1. To disclose and post all Rules & Regulations, Danger, Warning and Caution labels affi xed on the machine to their customers/users. 2. Equipment to be installed by TFI Authorized Dealer or a service company approved by TFI.
-
Page 2: Table Of Contents
Table of Contents OVERHEAD SPECIFICATIONS .................Page 3 DANGER, WARNING, & CAUTION LABELS INFORMATION ....Page 4-7 ANCHORING UNIT .....................Page 8 IMPORTANT SAFETY INSTRUCTIONS ............Page 9 REGISTRATION, SERVICE & ASSEMBLY ............. Page 10 INSPECTION/MAINTENANCE ..............Page 11 CABLE INSPECTION ..................Page 12 STEP 1-8 .......................Page 13-20 STEP 9-11 CABLE ROUTING ..............Page 21-24 STEP 12-14 ....................Page 25-27... -
Page 3: Overhead Specifications
Overhead Specifi cations L 71” X W 53” X H 58” L 180 cm X W 135 cm X H 148 cm PRODUCT WEIGHT 640 lb/291 kg www.tuffstuffi tness.com BA-706 BIO-ARC MID ROW... -
Page 4: Danger, Warning, & Caution Labels Information
Carefully read ALL Danger, Warning & Caution labels posted on the machine www.tuffstuffi tness.com BA-706 BIO-ARC MID ROW... - Page 5 Carefully read ALL Danger, Warning & Caution labels posted on the machine Chinese Utility Model Pat. No. ZL 201720321997.X www.tuffstuffi tness.com BA-706 BIO-ARC MID ROW...
- Page 6 Carefully read ALL Danger, Warning & Caution labels posted on the machine www.tuffstuffi tness.com BA-706 BIO-ARC MID ROW...
- Page 7 Carefully read ALL Danger, Warning & Caution labels posted on the machine Chinese Utility Model Pat. No. ZL 201720321997.X It is extremely important that the BE ALERT! Sign shown to the left be installed in plain view of the unit. You should have received it along with this Owners Manual.
-
Page 8: Anchoring Unit
Anchoring Unit Holes on footplates are provided for anchoring the unit to the fl oor. (See anchoring hole locations below) ANCHORING HOLE ANCHORING HOLES ANCHORING HOLES www.tuffstuffi tness.com BA-706 BIO-ARC MID ROW... -
Page 9: Important Safety Instructions
Important Safety Instructions It is the responsibility of the facility owner and/or owner of the equipment to review the Owner’s Manual with their facility personnel and understand all Danger, Warning and Caution labels affi xed on the machine. It is the responsibility of the fl oor personnel to instruct users on proper operation of the equipment and review all danger, warning and caution labels. -
Page 10: Registration, Service & Assembly
Registration, Service & Assembly Thank you for purchasing the BA-706 Bio-Arc Mid Row. This machine is part of the Tuff Stuff line of quality strength training equipment. To maximize your use of the equipment, please study the Owner’s Manual thoroughly. Registration Allow ample space around the machine for safe unrestricted use and easier access. -
Page 11: Inspection/Maintenance
Inspection/Maintenance Perform regular maintenance (see Inspection Label). Pay special attention to areas most susceptible to wear and tear, including but not limited to cables, pulleys and rubber grip. TFI recommends you maintain a service contract with a TFI Authorized Dealer or a Professional Service Company approved by TFI. -
Page 12: Cable Inspection
Cable Inspection WARNING: THE FOLLOWING CONDITIONS MAY INDICATE A WORN CABLE. REPLACE IMMEDIATELY. “NECKING”, STRECHED CABLE COVERING A CRACK IN THE CABLE COVER A TEAR IN THE CABLE COVER A BREAK ON THE CABLE CABLE END SLIPPING OUT IMPORTANT NOTE: DAMAGED OR WORNED CABLE (AS SHOWN ABOVE) MAY DAMAGE THE PULLEY(S). -
Page 13: Step 1
Step 1 Step 1 Assembly List Item Qty. Description TOP CROSS BRACE, MID ROW WEIGHT STACK FRAME MID ROW ASM BUTTON HEAD SOCKET CAP SCREW Z/P 1/2-13 X 1 FLAT WASHER SAE Z/P 1/2" SPLIT LOCK WASHER Z/P 1/2" Note: It is strongly recommended that two people participate in this assembly step. -
Page 14: Step 2
Step 2 Step 2 Assembly List Note: It is strongly recommended that two Item Qty. Description people participate in this assembly step. MID ROW UPRIGHT FRAME ASM BLACK DELRIN SPACER AND RANGE LIMITER, 1” ID BUTTON HEAD SOCKET CAP SCREW Z/P 1/2-13 X 1 FLAT WASHER SAE Z/P 1/2”... - Page 15 Step 3 Step 3 Assembly List Item Qty. Description MID ROW BASE FRAME ASM FLAT WASHER SAE Z/P 1/2" FLAT WASHER SAE Z/P 3/8" FLAT WASHER Z/P 1/2 X 1 3/4 X 3/16 HEX HEAD CAP SCREW Z/P 3/8-16 X 2 3/4 NYLON INSERT LOCK NUT Z/P 1/2-13 NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 HEX HEAD CAP SCREW Z/P 3/8-16 X 3...
- Page 16 Step 4 Run guide wire through Step 4 Assembly List hole in frame as shown below. Item Qty. Description BOTTOM CROSS BRACE (ROW/LAT) ASM FLAT WASHER SAE Z/P 1/2" FLAT WASHER SAE Z/P 3/8" FLAT WASHER Z/P 1/2 X 1 3/4 X 3/16 HEX HEAD CAP SCREW Z/P 1/2-13 X 3 1/4 HEX HEAD CAP SCREW Z/P 3/8-16 X 1 1/4 NYLON INSERT LOCK NUT Z/P 1/2-13...
- Page 17 Step 5 Step 5 Assembly List Item Qty. Description PIVOT AXLE 1 RD SS 303 X 4 7/16 (2X_1/2-13 UNC) PIVOT AXLE 1 RD SS 303 X 5 5/8, 2X 1/2-13 DEEP 1 SEAT FRAME MID ROW ASM ALUMINUM ROUND COVER PLATE, 2 1/2 FLAT HEAD SOCKET CAP SCREW Z/P 1/2-13 X 1 Fig.
- Page 18 Step 6 Step 6 Assembly List Item Qty. Description GUIDE ROD 3/4 X 47 3/4 MAGNETIC SELECTOR PIN W/COIL 3/8 X 5 FLAT WASHER SAE Z/P 3/8" HEX HEAD CAP SCREW Z/P 3/8-16 X 3 RUBBER DONUT 3/4 RD ID X 2 1/2 RD OD X 3 SPLIT LOCK WASHER Z/P 3/8"...
- Page 19 Step 7 Step 7 Assembly List Item Qty. Description LABEL-BIO-ARC WEIGHT STACK NUMBERS Weight stack labels and lubrication instructions 1. Wipe front surface of weight stack with rubbing alcohol and wipe dry. 2. Peel off back sheet (adhesive side) from label (#74) and make sure that the label remains attached to the application tape.
- Page 20 Step 8 Step 8 Assembly List Item Qty. Description LINEAR SHAFT COVER, ROW/LAT BUTTON HEAD SOCKET CAP SCREW Z/P 1/4-20 X 1/2 FLAT WASHER SAE Z/P #12 (1/4") Note: Remove covers as shown below to allow you to route the cable in the following steps. www.tuffstuffi...
-
Page 21: Step 9-11 Cable Routing
Step 9 Step 9 Assembly List Item Qty. Description MIDROW WEIGHT STACK CABLE BLACK NYLON PULLEY 3/8 X 1 X 3 1/2 BLACK NYLON PULLEY 3/8 X 1 X 4 1/2 FINISHED HEX NUT Z/P 1/2-13 FLAT HEAD SOCKET CAP SCREW Z/P 3/8-16 X 2 3/4 FLAT WASHER SAE Z/P 3/8"... - Page 22 Step 10 Step 10 Assembly List Item Qty. Description 3 1/2 ROUND CABLE RETAINER ADJ PULLEY BRACKET 4 BOLT 3 1/2 PULLEY 7/8 RD X 1 11/16 SPLIT LINK 3/16 CABLE BLACK NYLON PULLEY 3/8 X 1 X 3 1/2 BLACK NYLON PULLEY 3/8 X 1 X 3 1/2 (CUSTOM) BUTTON HEAD SOCKET CAP SCREW Z/P 1/4-20 X 3/4 CABLE STOPPER SHELL 1 1/2 X 1 3/4...
- Page 23 www.tuffstuffi tness.com BA-706 BIO-ARC MID ROW...
- Page 24 Step 11 Cable Adjustment Note: It is imperative that you maintain the cables’ proper adjustment to ensure a safe and smooth operation. Cable Bolt Cables should be inspected and adjusted periodically to avoid any slack in the cables which would, consequently, prevent any damage to the equipment or personal injury.
- Page 25 Step 12 Step 12 Assembly List Item Qty. Description LINEAR SHAFT COVER, ROW/LAT BUTTON HEAD SOCKET CAP SCREW Z/P 1/4-20 X 1/2 FLAT WASHER SAE Z/P #12 (1/4") Fully Tighten 100% Wrench tighten all hardware in this step. www.tuffstuffi tness.com BA-706 BIO-ARC MID ROW...
- Page 26 Step 13 Step 13 Assembly List Item Qty. Description FRONT WEIGHT SHIELD ASM SHIELD, REAR (MPC-0103-WLD) FLAT HEAD SOCKET CAP SCREW Z/P 1/4-20 X 3/4 *107 TOP PLASTIC COVER ASM MIDROW *107 Fully Tighten 100% Wrench tighten all hardware in this step. www.tuffstuffi...
- Page 27 Step 14 Step 14 Assembly List Item Qty. Description STANDARD PAD FLAT WASHER SAE Z/P 3/8" HEX HEAD CAP SCREW Z/P 3/8-16 X 1 1/2 Fully Tighten 100% Wrench tighten all hardware in this step. www.tuffstuffi tness.com BA-706 BIO-ARC MID ROW...
-
Page 28: Parts List
10 MAGNETIC SELECTOR PIN W/COIL 3/8 X 5 GOLD KNOB UP2209 70 LABEL SERIAL NUMBER CLASS S BNH5186 11 MID ROW BASE FRAME WLDMT UP8767 71 LABEL TFI TUFFSTUFF FITNESS INTERNATIONAL BNH1058 12 MID ROW UPRIGHT FRAME WLM UP8733 72 LABEL WARNING ANCHOR BOLT, 2 X 1 1/4" BNH3089... - Page 29 Pre-Assemble Components *110 BNH3533 *107 BNH4362X6 *25 UP8764X1 *16 UP8918X6 www.tuffstuffi tness.com BA-706 BIO-ARC MID ROW...
- Page 30 Pre-Assemble Components *11 UP8767X1 www.tuffstuffi tness.com BA-706 BIO-ARC MID ROW...
- Page 31 Pre-Assemble Components *24 UP8729X1 UP8743X1 *115 UP8705X1 *12 UP8733X1 *109 BNH3535X1 www.tuffstuffi tness.com BA-706 BIO-ARC MID ROW...
-
Page 32: Warranty
Website: www.tuffstuffitness.com This warranty applies only in the United States to the products manufactured or distributed by TuffStuff Fitness International Inc. under the TUFFSTUFF brand name. TuffStuff warrants to the original purchaser that TuffStuff equipment will be free from defects in material and workmanship. All warranty periods begin to run from the date of purchase to the original purchaser.
