Step 11 Cable Adjustment
Note:
It is imperative that you maintain the cables' proper adjustment to ensure
a safe and smooth operation.
Cables should be inspected and adjusted periodically to avoid any
slack in the cables which would, consequently, prevent any damage
to the equipment or personal injury.
Mid Row Cable Adjustment:
Loosen Lock Nuts and slide Adj Pulley
Bracket in or out to give cable proper
tension. Re-tighten Lock Nuts.
Adj Pulley Bracket
Fully Tighten
100%
Proceed to inspect; align and wrench tighten ALL hardware
assemblies specially those left loosely fasten.
www.tuffstuffi tness.com
24
Lock Nut
Cable Bolt
Hex Nut
Weight Stack Cable Adjustment:
Loosen Hex Nut and thread Cable Bolt
in or out to give cable proper tension.
Re-tighten Hex Nut.
CABLE BOLT MUST BE THREADED
A MINIMUM OF 1" WITH HEX NUT
TIGHTENED SECURELY TO ENSURE
PROPER CONNECTION.
