- Page 1 O W N E R ’ S M A N U A L 84" 59" 50 3/4" RHL-305WS High/Low Pulley W/200 Lbs Steel Wt Stack (for RPR-265) ’ MERICA REMIER XERCISE QUIPMENT RHL-305WS Rev0 Revision Date 5-30-2007...
- Page 2 FLAT WASHER SAE 3/8” HEX HEAD CAP SCREW 3/8-16 X 1 3/4 HEX HEAD CAP SCREW 3/8-16 X 5 HEX HEAD CAP SCREW 5/16-18 X 3/4 NYLON INSERT JAM LOCK NUT 3/8-16 RHL-305WS High/Low Pulley W/200 Lbs Steel Wt Stack (for RPR-265)
- Page 3 GUIDE ROD 3/4 X 71 31/32 SELECTOR PIN W/COIL 3/8 X 4 10 LB STEEL WEIGHT PLATE BLACK 10 LB TOP PLATE W/22” SLTR BAR DECAL-WEIGHT NUMBERS RUBBER DONUT 3/4 X 2 1/2 RHL-305WS High/Low Pulley W/200 Lbs Steel Wt Stack (for RPR-265)
- Page 4 HEX HEAD CAP SCREW 3/8-16 X 2 1/2 NYLON INSERT JAM LOCK NUT 3/8-16 Note: Lift the Guide Rods to allow the insertion of the two Hex Head Cap Screws RHL-305WS High/Low Pulley W/200 Lbs Steel Wt Stack (for RPR-265)
- Page 5 RHL-305WS Cable Routing Diagram FIG. A FIG. B FIG. C RHL-305WS High/Low Pulley W/200 Lbs Steel Wt Stack (for RPR-265)
- Page 6 RHL-305WS Exploded View Diagram RHL-305WS High/Low Pulley W/200 Lbs Steel Wt Stack (for RPR-265)
- Page 7 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 3/8 BNH2043 STRAP BRACKET 20 #SF20 BNH0562 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3 BNH2046 DECAL-FOR BEST PERFORMANCE BNH0143 RHL-305WS High/Low Pulley W/200 Lbs Steel Wt Stack (for RPR-265)
