- Page 1 Dolphin Oasis Z5 Robotic Cleaner Dolphin Oasis Z5 Users Manual Also known as the Explorer Classic or Top 9 Cleaner Oasis Z5 Also known as Top 9 Classic 9 8151620_Explorer_cover1_all lang.indd 1 6/03/13 2:26 PM...
-
Page 2: Table Of Contents
Dolphin Explorer Classic 9 / Top 9 User Instructions Contents 1. INTRODUCTION ............... 2 2. SPECIFICATIONS............... 2 3. WARNINGS AND CAUTIONS ........... 2 3.1. Warnings ................2 3.2. Cautions ................2 4. POOL CLEANER PARTS ............3 5. USING THE POOL CLEANER ............ 4 5.1. -
Page 3: Introduction
Thank you for purchasing a Maytronics Robotic Pool Cleaner. We are sure that your Maytronics Robotic Pool Cleaner will provide you with reliable, convenient and cost effective pool cleaning. Its reliable filtration in all pool conditions, active brushing, and all-surface climbing brush enhance maximum pool hygiene. -
Page 4: Pool Cleaner Parts
For concrete, PVC, For smooth ceramics. fiberglass and liner. fiberglass and liner. Power supply unit Filtration Cartridge with Net filters (X4) Ultra-fine filter (X4) (optional) Dolphin Explorer Classic 9 / Top 9 User Instructions 8151620_Expolorer_all languages.indd 3 6/03/13 5:25 PM... -
Page 5: Using The Pool Cleaner
A. Press the latch down and hold it in position. B. Move the handle to the desired position and release the latch to hold the handle in place. Dolphin Explorer Classic 9 / Top 9 User Instructions 8151620_Expolorer_all languages.indd 4 6/03/13 5:25 PM... -
Page 6: Putting The Pool Cleaner Into The Pool
To avoid kinks in the floating cable, place approximately enough cable in the water for the Pool Cleaner to reach the farthest corner of the pool. Dolphin Explorer Classic 9 / Top 9 User Instructions 8151620_Expolorer_all languages.indd 5 6/03/13 5:25 PM... -
Page 7: Removing The Pool Cleaner From The Pool
Using the floating cable, bring the Pool Cleaner to the pool’s edge. Using the handle remove the Pool Cleaner from the pool. DO NOT PULL THE POOL CLEANER FROM THE POOL USING THE CABLE. CAUTION Dolphin Explorer Classic 9 / Top 9 User Instructions 8151620_Expolorer_all languages.indd 6 6/03/13 5:25 PM... -
Page 8: Routine Maintenance
1. Open the filter covers and remove the cartridges from both sides of the robot. 2. Open the clips and remove the filters. 3. Clean the filters with a hose. Dolphin Explorer Classic 9 / Top 9 User Instructions 8151620_Expolorer_all languages.indd 7... -
Page 9: Dismantling And Cleaning The Impeller
6.2. Dismantling and cleaning the impeller Unplug the power supply before cleaning. CAUTION Dismantle the impeller cover and clean around the impeller housing, then reassemble. (Use Phillips head screwdriver). Dolphin Explorer Classic 9 / Top 9 User Instructions 8151620_Expolorer_all languages.indd 8 6/03/13 5:26 PM... -
Page 10: Off Season Storage
• Roll up the cable so that it has no kinks and place on the Caddy • Store the pool cleaner upright on the Caddy in a protected area out of direct sun/rain/frost at a temperature of between 5˚-45˚C / 41˚-113˚F Dolphin Explorer Classic 9 / Top 9 User Instructions 8151620_Expolorer_all languages.indd 9... -
Page 11: Troubleshooting
To move the floats back to their original position: while pressing the release button on the base of the handle float – push the handle float back. Dolphin Explorer Classic 9 / Top 9 User Instructions 8151620_Expolorer_all languages.indd 10... - Page 12 8151620_Explorer_cover1_all lang.indd 3 6/03/13 2:26 PM...
