RC Factory Mini Crack Pitts Building Instructions page 3

1.
Cut
2x carbon 3x0,5x500mm = 6x0,5x500mm
Upper + lower wing
3.
Cut
5.
Glue CA
7.
c.
a.
0,8x330mm
9.
Upper + lower wing
Cut
Glue CA
Cut Cut
5x
Glue CA
b.
1x60mm
2.
Cut
carbon 3x0,5x100mm
Glue CA
4.
Cut
c.
6.
a.
b.
b.
8.
2x carbon 3x0,5x110mm
(6x0,5x110mm)
10.
Cut
Cut
carbon 3x0,5x110mm
Glue CA
b.
a.
Glue CA!
2x carbon 3x0,5x70mm
(6x0,5x70mm)
Cut
L+R
cca 5mm
(14pcs)
Lower wing
