RC Factory Clik 4 NG Manual

Clik 4 NG
840 mm 940 mm 120g

Kit Contents:

*Fuselage
*Wings
*Backbone
*Horizontal Stab
*Vertical Stab

Acessory Pack

Contents:
1x mall parts S for landing gear
6x lastic clevises P
1x eatshrink tube H
4x djustable link+quicklock washer A
1x Plastic frame

Plastic frame:

1. Aileron servo horn
2. Elevator, rudder horns
3. Aileron horns
4. Motor mount
5. Wing/torsion bracing fuselage root
6. Landing gear parts
You Will Also Need:
* sharp hobby knife
* screwdriver
* pliers
* round needle file
Li-pol 2s
120-200
*SFG's
*Landing gear
* Acessory Pack
*T-Canalyser

*Carbon reinforcements:

- 2x- 0,8x500 ... Stabs pushrods
- 3x0,5x680 ... Wing spar
- 3x0,5x500 ... Wing reinforcement
- 4x- 1x250 ... Wing strut
- 2x- 3x0,2x440 ... Aileron reinforcement
- 2x- 1,5x220 ... Landing gear
- 7x- 0,8x500 ... Backbone reinforcement
- 2x- 1x200 ... Aileron pushrod
- 3x0,2x330 ... Elevator reinforcement
12x E levator/rudder pushrod leads
2x Wheel
Carbon 3x0,2x75 ... Rudder reinforcement
2x Carbon 3x0,2x150 ... Fuselage reinforcement
2x Carbon 1,5x15 ... Wheel axle
3
1
6
3
* CA medium+thin, CA kicker
* ruler
* sandpaper 100-500
* thread
V1.0
2
5
4 6
5
2
