AUSSIE TONNEAU ATB01018 Fitting Instructions

Cover for ford px ranger dual cab (with head board), nov 2011-may 2013

Ford PX Ranger Dual Cab (with head board), Nov 2011-May 2013

Drill, 4mm Drill Bit, Tape Measure, Rivet Gun, Marking Pencil / Pen, Clear Silicone / Silicone Gun

1 x Tonneau Cover

1 x Tonneau Support Bar – Bar Adjustable

3 x Aluminium Rope Track- 403mm long ea.

2 x 100mm angle pieces (S-0047)

1 x Fitting Instructions

Tonneau Cover Fitting Instructions

Part Number:

BASIC TOOLS REQUIRED

ATB01018

2 x Bar Brackets

30 x Rivets

18 x Rope Buttons

4 x Dowel

Table of Contents

Do you have a question about the ATB01018 and is the answer not in the manual?

Page 1 Tonneau Cover Fitting Instructions Ford PX Ranger Dual Cab (with head board), Nov 2011-May 2013 ATB01018 Part Number: BASIC TOOLS REQUIRED Drill, 4mm Drill Bit, Tape Measure, Rivet Gun, Marking Pencil / Pen, Clear Silicone / Silicone Gun CONTENTS 1 x Tonneau Cover 2 x Bar Brackets 1 x Tonneau Support Bar –...
Page 2 INSTALLATION PROCEDURE NOTE Read entire instructions prior to start. STEP 1 Fit the pieces of angle to the outside edge of the head board making sure the top flat edge of the angle is at the same height as the top lip of the head board. Drill two 4mm holes in each piece of angle, silicone behind is, then rivet into place STEP 2 Using two pieces of dowel, join the 3 aluminum rope tracks together.
Page 3 Insert a dowel [J] half way into each end of the rope track [E]. Ensuring the rounded section (1) of the rope track faces away the cabin, sit the rope track against the front (cabin end) inside vertical surface of the tub (2) & centralise the rope track. Figure 1 Placement of aluminium rope track.
Page 4 MULTI-FIT SUPPORT BAR The Aussie Tonneau Multi - Fit Support Bar is designed to fit almost all Utes on the Market, from Suburu Brumbys to Cab Chassis aluminium trays. BASIC TOOL REQUIRED Drill, 4mm drill bit MULTI-FIT SUPPORT BAR CONTENTS...
