NOTE: The right and left jacks are used to level the coach side-to-side. Pressing the LEFT button on the
touchpad will extend both left jacks. Pressing the RIGHT button on the touchpad will extend both
right jacks. Jacks always work in pairs; both front jacks, both right side (curbside) jacks, etc.
6.
Repeat steps 2-5 if needed.
7.
Press the ON/OFF (power) button (Fig. 1K) to turn the leveling system off.
8. Visually inspect all jacks to ensure all footpads are touching the ground. For example, if one of the rear
jack footpads is not touching the ground, press the corresponding LEFT or RIGHT button to lower the
non-compliant jack to the ground.

Jack Retract Procedures

1.
Press the ON/OFF (power) button (Fig. 1K) to turn the leveling system on. The LCD screen (Fig. 1E) will
display "JACKS DOWN."
2. Press the Down Arrow button (Fig. 1B) to display "AUTO RETRACT" on the LCD screen.
3.
Press the ENTER button (Fig. 1C) to begin automatically retracting the jacks.
NOTE: To stop the jacks from retracting, turn the leveling system off, then back on again by pressing the
ON/OFF (power) button twice. Do steps 1-5 of the Manual Leveling Procedure section to manually
level the coach. Press the ENTER button to acknowledge.
4.
When the "JACKS DOWN" message on the LCD display goes off, press the ON/OFF (power) button to
turn the leveling system off.
A. Do a visual inspection around the coach to verify all jacks are fully retracted.
B. If all jacks are fully retracted, the coach is ready for travel.
5. To retract jacks while in MANUAL mode:
A. Press the RETRACT button (Fig. 1D) until it lights.
B. By pressing any of the jack buttons (Fig.1G-J), the jacks will retract in pairs i.e., pressing the FRONT
button makes both front jacks retract in unison.
6.
An "auto retract" sequence can also be performed by pressing and holding the RETRACT button
(Fig. 1D) for one second.
NOTE: In cold weather operation, always check to make sure all jacks, slide rooms and steps are fully
retracted before traveling.

Leveling System Safety Features

1.
The leveling system will automatically shut down after four minutes of no operation.
2.
Auto leveling cycle cannot be started until all jacks are fully retracted.
A. Make sure jacks are retracted before attempting to auto level.
B. The leveling system will automatically perform a full retract of all jacks if jacks are down when
there is a request for an auto cycle.
3.
The leveling system will refuse any operation when a low voltage condition is present.
4. The leveling system will automatically sound an alarm and retract all jacks if the PARK BRAKE is
disengaged and jacks are not retracted with any change in sensor readings.
NOTE: When the leveling system is in alarm mode, only the "retract all jacks" feature is available.
5. If the "WAIT" message displays in the touchpad's LCD screen (Fig. 1E), this indicates the status of
Air/Auxiliary features.
NOTE: The touchpad's LEDs blink differently when in special controller modes e.g., error, alarm,
configuration. Recognizing these modes is important i.e., Excess Angle LED blinks whenever the
Y-axis (vehicle length) is over five degrees from the programmed level point.
