Hydraulic Power Unit
See figures 9 and 10 for hydraulic power unit feature identification and the following:
• Fittings - High Pressure O-Ring Face - Size 4
1/4
• Hose -
" I.D. 3000PSI - W.P. Rated
NOTE: Fittings are labeled with port assignments found stamped into the manifold for easy identification.
Motor Solenoid
12V DC
Power
Ground
Power
Rev: 11.18.19
Fig. 9
Page 16
12V DC Motor
CCD-0001535
