ONECONTROL
Introduction
The OneControl® ConnectAnywhere
OneControl-compatible Controller Area Network (CAN) controllers.
This document provides instructions on how to activate the ConnectAnywhere system and associate it to the LCI
Customer Community website.
Resources Required
ConnectAnywhere parts needed for system activation (Fig. 1):
A
Rev: 02.12.19
CONNECTANYWHERE
®
ELECTRONICS
is an electronic control system that allows worldwide remote control of LCI
TM
Fig. 1
C
B
Callout
Description
A
ConnectAnywhere Cellular Gateway
B
ConnectAnywhere Cloud Gateway
C
Nano SIM Card (carrier-provided)
D
External Roof Mount Antenna
E
Android or iOS Smart Device
Page 1
ACTIVATION
TM
D
E
CCD-0001843

Advertisement

loading
Need help?

Need help?

Do you have a question about the OneControl ConnectAnywhere and is the answer not in the manual?

Questions and answers

Related Manuals for Lippert Components OneControl ConnectAnywhere

Summary of Contents for Lippert Components OneControl ConnectAnywhere

  • Page 1 ONECONTROL CONNECTANYWHERE ACTIVATION ® ELECTRONICS Introduction The OneControl® ConnectAnywhere is an electronic control system that allows worldwide remote control of LCI OneControl-compatible Controller Area Network (CAN) controllers. This document provides instructions on how to activate the ConnectAnywhere system and associate it to the LCI Customer Community website.
  • Page 2 ONECONTROL CONNECTANYWHERE ACTIVATION ® ELECTRONICS Preparation Locate the ConnectAnywhere hardware (Fig. 2). NotE: The ConnectAnywhere hardware is typically located in a cabinet in the middle of the unit (Fig. 2A) or in a pass-through storage unit (Fig. 2B). Refer to the unit's floor plan or User Guide for additional information.
  • Page 3 Before visiting AT&T® or Rogers™ (CAN), make sure to have the IMEI (International Mobile Equipment Identity) number available. The IMEI number is printed on the OneControl ConnectAnywhere Cellular Gateway label (Fig. 3C). NotE: The IMEI number is a unique 15-digit serial number given to every cellular mobile device, which can then be used to check information such as the phone's Country of Origin, the Manufacturer and it's Model Number.
  • Page 4 ONECONTROL CONNECTANYWHERE ACTIVATION ® ELECTRONICS If using a standard size SIM card, do as follows: Disconnect power from the cellular gateway (Fig. 5A). Locate the SIM card slot on the side of the cellular gateway (Fig. 6A). Inspect card slot for provided SIM card adapter. If installed, remove adapter. Press and release card adapter to eject it from the slot.
  • Page 5 ONECONTROL CONNECTANYWHERE ACTIVATION ® ELECTRONICS Fig. 7 nano nano standard SIM card SIM card Adapter SIM card Download (Fig. 8A) and install (Fig. 8B) the LCI OneControl app from either Apple's App Store (iOS) or Google Play (Android). Fig. 8 App Store ®...
  • Page 6 ONECONTROL CONNECTANYWHERE ACTIVATION ® ELECTRONICS Activation NotE: Screen images vary depending on the device used to register, activate or operate the OneControl ConnectAnywhere system. The following screen captures (Figs. 9-13) reflect an iOS smart device. Connecting to A Secured Wi-Fi Network Secured Wi-Fi networks are password-protected.
  • Page 7 ONECONTROL CONNECTANYWHERE ACTIVATION ® ELECTRONICS Select the name of the desired, secured Wi-Fi network (Fig. 10A). NotE: This network name will be the SSID name (Fig. 3A) printed on the cellular gateway label. Enter the PASSWoRD (Fig. 11) located on the cellular gateway label (Fig. 3B). NotE: Passwords are case sensitive and do not contain numerals .
  • Page 8 ONECONTROL CONNECTANYWHERE ACTIVATION ® ELECTRONICS When joined with the network, a check mark will appear next to the network name (Fig. 12A) and the connectivity symbol will appear in the upper left corner of the mobile device's display. Verify connectivity by opening a web browser on the mobile device and navigate to www.lci1.com/onecontrol.

  • Page 9: System Registration

    ONECONTROL CONNECTANYWHERE ACTIVATION ® ELECTRONICS System Registration The KCoDE (Fig. 4A) is automatically read during activation when using the OneControl app. NotE: If registering on-line using a desktop or laptop PC, the KCoDE will have to be entered manually. To register the ConnectAnywhere system, do as follows: Go to https://lippert.force.com/IoTCommunity/register.
  • Page 10 ONECONTROL CONNECTANYWHERE ACTIVATION ® ELECTRONICS After completing setup, log into the LCI OneControl app by selecting the Menu (cog wheel) (Fig. 15A). Enter login credentials, then click the Login button (Fig. 16A). Fig. 15 Fig. 16 ConnectAnywhere system registration is now complete (Fig. 17). Fig.
