6.
Using a 1/2" socket and auxiliary drive device, e.g., cordless or electric power drill, insert 1/2" socket onto
the coupler (Fig. 4A).
7. Run drive device in reverse (counterclockwise) to retract jacks (Fig. 4)—forward (clockwise) to
extend jacks.
8. After the jacks have been fully extended or retracted, remove the 1/2" socket and drill from the
motor's coupler.
9.
Reinsert the 5/32" hex wrench into the valves' manual override adjustment (Fig. 5A).
10. Turn the valve's manual override completely counterclockwise (Fig. 5) until the adjustment no longer
turns, thus completely closing the valves.
11. Do not over-tighten override set screws, as this can damage the valves.
Rev: 11.18.19
Fig. 4
Run Counterclockwise to Manually
Retract Jacks.
Fig. 5
Counterclockwise for normal operation
Page 11
A
A
CCD-0001535
