- Page 1 Service Manual up to Serial No. 8698 Vacuum-Belt 5314 / 5316 Applicator Made in Germany...
- Page 2 9009638 Copyright This documentation as well as translation hereof are property of cab Produkttechnik GmbH & Co. KG. The replication, conversion, duplication or divulgement of the whole manual or parts of it for other intentions than its original intended purpose demand the previous written authorization by cab.
-
Page 3: Table Of Contents
Table of contents Operation Introduction ............................4 Instructions ............................... 4 Intended Use ............................4 Safety Instruction ............................. 4 Safety Marking ............................5 Environment ............................. 5 Product Description ..........................6 Important Features ........................... 6 Technical Data ............................6 Device Overview ............................. 7 Contents of Delivery .......................... -
Page 4: Introduction
• The device applicator mounted on a cab printer of the Hermes+ series is intended exclusively for applying suitable materials that have been approved by the manufacturer. Any other use or use going beyond this shall be regarded as improper use. -
Page 5: Safety Marking
Introduction During operation do not reach into that zone and keep long hair, loose clothes, and jewelry distant. • The device may only be used in a dry environment, do not expose it to moisture (sprays of water, mists, etc.). •... -
Page 6: Product Description
Product Description Important Features • For operation in a system the I/O interface of the printer can be used. Technical Data Technical data Vacuum-Belt Vacuum-Belt Applicator 5314 Applicator 5316 Label width Hermes+4 mm 20 – 114 – Hermes+6 mm – 50 –... -
Page 7: Device Overview
Product Description Device Overview without cover of the control unit Fig.2 Overview 1 SUB-D 15 Interface to the printer 9 Connector to SUB-D 15 Interface to the printer 2 EEPROM 10 Connectors to the fans 3 Interface sensor on board PCB control 11 Motor belts 4 Sensor 12 Connector motor belts... -
Page 8: Contents Of Delivery
Product Description Contents of Delivery Fig.3 Contents of delivery 1 Applicator mounted 2 Screws to mount on the printer 3 Documentation Notice! Please keep the original packaging in case the applicator must be returned. Attention! The device and printing materials will be damaged by moisture and wetness. ... -
Page 9: Operation
Operation Standard Operation Check all external connections. Load the material. "Operator's Manual" of the printer. Switch on the printer. Press the feed key at the printer. A synchronization feed is released. The processed labels have to be removed manually. After a few seconds the printer carries out a short backfeed to position the front edge of the next label at the printing line. -
Page 10: Error Messages
Error Messages Error Messages of the Printer For detailed information about printer errors (e.g. 'Paper out', 'Ribbon out', etc.) Operator's manual of the printer Error treatment : Clear the error results Press the feed key to synchronize the label feed, remove the peeled labels manually ... -
Page 11: Licences
Person authorised to compile the technical file : Erwin Fascher Am Unterwege 18/20 99610 Sömmerda Signed for, and on behalf of the Manufacturer : Sömmerda, 17.06.2015 cab Produkttechnik Sömmerda Gesellschaft für Computer- und Automationsbausteine mbH Erwin Fascher 99610 Sömmerda Managing Director The product must not be put into service until the final machinery into which it is to be incorporated has been declared in conformity with the provisions of the Directive on machinery The documents according annex VII part B from the incomplete machinery are created and will commit to state agencies on request in electronic kinds. -
Page 12: Eu Declaration Of Conformity
Directive 2011/65/EU on the restriction of the use of certain • EN 50581:2012 hazardous substances in electrical and electronic equipment Signed for, and on behalf of the Manufacturer : Sömmerda, 17.06.2015 cab Produkttechnik Sömmerda Gesellschaft für Computer- und Automationsbausteine mbH Erwin Fascher 99610 Sömmerda Managing Director... -
Page 13: Installation
In case of a customer setup with special material the adjustments can deviate from standard values. Then the values in the setup protocol are valid. The standard values for the settings ex-factory are: Connecting on a cab Hermes+ printer, vertical Used material for ex-factory settings: cab part No.: 5556472 54x35.5... -
Page 14: Tools
Installation Tools • Crosstip screwdriver to adjust the sensor (Phillips) • Hexagon kay L-wrench for matched norm parts (in delivery state of the applicator) to set the angle of the applicator to adjust the pressure roll • Flat-round noise straight angled Table 3 Tools... -
Page 15: Mounting
Installation Mounting Fig.5 Mounting 1 Lay on the printer (1) on the rear side - print unit and material guiding on top. 2 Move the applicator (6) so in position to the printer that the holes in the mounting plate (4) are over the holes in the base of the printer (1) . -
Page 16: Adjustments
Adjustments Notice! The right position of the applicator to the printer is adjusted ex factory and is not to change. Adjust only the Degree of the applicator to the printer and the pressure of the pressure roll. Adjust the angle to the printer max 45°... -
Page 17: Adjustment Of The Printer Setup
Adjustments Adjustments in the Printer Setup Label transport / Reflex sensor Fig.8 Waiting position of the label The operation mode "Blow" must be selected in the setup. Only with this setting it is possible to change the parameter "Blow time" . After detecting the label (2) by the reflex sensor (1) it will be transported further for a defined time to reach the pressure roll (4). To change this overrun time use the parameter >... -
Page 18: Configuration
Configuration Quick Mode for Setting the Delay Times On the applicator it is possible to set the transport speed of the label in four steps. By the parameter Support del. off . Beside the standard method for the printer configuration there is a quick mode to adjust the delay times available. Notice ! The quick mode settings can be made during operation . The changes affect directly the current print job. 1. -
Page 19: Setting The Peel Position
Configuration Setting the Peel Position To optimize the transfer of the labels from the printer to the applicator there two different parameters are available for adjusting the peel position. Attention! First adjust the parameter "Peel Position" in the printer configuration. Following adjust the additional peel-off offset in the software. It is very important to follow that procedure for a certain start after label loading and for the re-start after error treatment. -
Page 20: Operation
Operation Test Mode without Print Job Warning! In operation of the applicator movable parts are accessible. It is particularly in the area of belt and fans. Do not reach into the zone of the moving parts and keep long hair, loose clothes, and jewelry distant. Fig.9 Test mode via Enter key Notice! -
Page 21: Spare Parts
Spare Parts 10.1 Support Assembly / Transport Part-No. Description Serial No. Part-No. Description Serial No. from from 5902282.001 Screw DIN7984 M5x20 11.1 5971491.001 Motor Shaft 5903041.001 Washer DIN125-A5.3 11.2 5972137.001 5971488.001 Side Plate 5971493.001 Adapter Plate 5971679.001 Support 5902016.001 Screw DIN7991-M4x10 5971507.001 Support 14.1 5971696.001 Ground Plate... -
Page 22: Control Unit / Contact Pressure
Spare Parts 10.2 Control Unit / Contact Pressure Part-No. Description Serial No. Part-No. Description Serial No. from from 5903054.001 Washer DIN988-10x16x1 5902375.001 Screw DIN7984-M6x10 5902016.001 Screw DIN7991-M4x10 5971677.001 Lever 5902241.001 Screw DIN7984-M4x10 5971684.001 Bolt 5903510.001 E-Ring DIN6799-9 5902536.001 Nut DIN439 M6 20.1 5971497.001 Foam Roll 5314... -
Page 23: Fan
Spare Parts 10.3 Part-No. Description Serial No. from 5971790.001 Fan 5902015.001 Screw DIN7991-M4x35 5902570.001 Nut DIN982-M4 5907065.001 Protective Grid 92x92 3x 5314 6x 5316 Fig.12 Fan - Spare Parts... -
Page 24: Block Diagram
Block Diagram EEPROM SUB-D 9 Anschluss zum Applicator Control Drucker Motor Belt Unit Sensor Label Detecting Fig.13 Block diagram... -
Page 25: Index
Index Index Block Diagram ........24 Cleaning ..........9 Conformity ........12 Control Unit........22 Delay Time........18 Delay Times ........18 Delivery..........8 Environment ........5 Error Messages ........10 Fan ...........23 Features ..........6 Incorporation........11 Instruction ...........4 Mounting ...........15 Operation ..........9 Parameter .........18 Peel-off Mode ........19 Peel Position........19 Pressure rol ........16 Printer Setup........17 Print Job ...........20...
