Homestyles Cabin Creek 88 5411 49 Manual

88 5411 49
Cabin Creek
Hall Tree Stand

IMPORTANT NOTE

Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.

Part List

A.
Seat
1 pc.
E.
Shelf
1 pc.
F. G.
Side Frame Side Frame
1 pc. 1 pc.

Hardware List

Hex Wrench
1 pc.
Small
Flat Washer
Hex Wrench
56 pcs. (+1 extra )
1 pc.
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
Side Frame
H.
I.
Back Frame
Back Frame
1 pc. 1 pc.
Head Cap Bolt
Head Cap Bolt (short)
for Stertcher (M)
45 pcs. (+1 extra)
4 pcs. (+1 extra)
Head Cap Bolt (long)
2 pcs. (+1 extra)
B.
2 pcs.
Spring Washer
56 pcs. (+1 extra )
Head Cap Bolt Wood Screw (long)
5 pcs. (+1 extra) 4 pcs. (+1 extra)
Tools recommended for assembly : Level
C.
Back Frame
1 pc.
Tapered
Head Cap Bolt
4 pcs. (+1 extra)
Wood Screw
4 pcs.(+1 extra)
D.
Stretcher
1 pc.
J.
Top
1 pc.
K.
Stretcher
1 pc.
L.
Shelf
1 pc.
M.
Stretcher
1 pc.
Steel Plate Connecter
2 pcs.(+1 extra)
