Egholm 2100 Operator's Manual

Lawn edger - changeable blade
Hide thumbs Also See for 2100:
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATOR'S MANUAL
Lawn Edger
- Changeable blade
90101431-01 GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Egholm 2100

Summary of Contents for Egholm 2100

  • Page 1 OPERATOR’S MANUAL Lawn Edger - Changeable blade 90101431-01 GB...
  • Page 2 Reservations: As it is the Egholm policy to make continuous improvements, we reserve the right to alter the specifi - cations and equipment at any time without notice. Egholm Maskiner A/S accepts no liability for errors or shortcomings in the operator’s manual.

  • Page 3: Table Of Contents

    Useful tips To give the complete fi nish when cutting lawns Best results are achieved when the ground is a fi x the Lawn Edger onto the Egholm 2100. little damp. The Lawn Edger cuts the edges of the grass Never drive too fast for the Lawn Edger to cut effi...

  • Page 4: General Information

    1. General information 1.1 Safety Make sure no one stands too close to the machine: Make sure there is no one close to the machine when it is in use, as there is danger of crushing. Prevent people from standing N.B: in the working area.

  • Page 5: Ec Declaration Of Conformity For Machinery

    - has been manufactured in conformity with the provisions of the Machinery Directive, Directive 98/37/EU The Egholm 2100 fi tted with the cab FH 2100 (ROPS approved) - has been tested at the Danish Institute of Agricultural Sciences at Bygholm in...

  • Page 6: Technical Data

    1. General information 1.3 Technical data Dimensions: All measurements Assembled: Storage in mm dimension: Length (L): 2,580 mm 600 mm Width (W): 1,140 mm 820 mm Height without cab (H): 515 mm 360 mm Height with cab: 1,935 mm Side view Technical data: Type description: VKS 1...

  • Page 7: Instructions For Use

    2. Instructions for use 2.1 Assembly / disassembly 1. Keep the hydraulic hoses clear and free from dirt when the Lawn Edger is being fi tted. 2. The locking handle on the A-frame of the basic ma- chine must be in the open position, and the A-frame must be raised so that it is vertical when viewed from the side.

  • Page 8: Important Before Start-Up

    2. Instructions for use 2.2 Before start-up During transport lock the Lawn Edger in the raised position with the transport lock. (Picture 1) Warning! Do not drive over well covers or similar obstacles, to avoid damaging the edger. Transport lock 2.3 Start-up Right side Right side...

  • Page 9: Adjustment

    2. Instructions for use 2.4 Adjustment Right side Right side Adjust the working depth to suit the conditions. Adjusting the working depth: 1. Stop the Lawn Edger by pushing lever D on the right-hand side of the machine down to position 0. (Picture 1) Stop Lawn Edger - lever D in pos.

  • Page 10: Changing The Blade

    2. Instructions for use 2.5 Changing the blade The blade on the Lawn Edger is changeable, which means that you can choose whether to cut inwards or outwards. The blade is changed according to the placing of the machine in relation to the edge of the lawn.

  • Page 11: Service And Maintenance

    3. Service and maintenance 3.1 Cleaning Daily cleaning and maintenance will extend the lifetime of both the machine and the attachment. Clean the Lawn Edger with water after use. 3.2 Maintenance Remove the protective guard – bolts Changing the cultivator blades: 1.
  • Page 12 The screws which hold the wearing block the disc and the shaft. New blades, discs and wearing blocks can be ordered from an authorised Egholm distributor. Winter storage: When it is time to store the Lawn Edger for the winter, we recommend the following: 1.

  • Page 13: Conditions

    Egholm Maskiner A/S has no control. The scope of warranty: 1. The Egholm warranty is only valid on presentation of the original receipt supplied with model description, serial number and date of purchase.

  • Page 14: Complaints

    Best regards Egholm Maskiner A/S - Transportvej 27 - DK -7620 Lemvig, tel: +45 97 81 12 05, fax: +45 97 81 12 10 4.3 Disposal When – many years from now – your Egholm Lawn Edger comes to the end of its working life, it should be disposed of in a responsible manner and conform with the relevant disposal regulations.
  • Page 15 Notes...
  • Page 16 Egholm Maskiner A/S * Transportvej 27 * DK-7620 Lemvig Tel.: (+45) 97 81 12 05 * Fax: (+45) 97 81 12 10 www.egholm.dk * egholm@egholm.dk...
