Lift Link Assembly - Big Joe EZ30 Operation, Maintenance, Repair Parts List

Pos. Part Number
1 1115-131000-K0
2 0000-000294-00
3 0000-000675-00
3a 0000-000906-00
4 0000-000101-00
5 1115-132100-00
1115-132000-K0
6
7 0000-000011-00
7a 0000-000907-00
8 1115-130005-4A
9 0000-000029-00
9a 0000-000908-00
10 1115-130003-00
11 0000-000708-00
11a 0000-001456-00
12 1115-130007-40
13 1115-133000-40
13a 1220-130003-00
14 See Pos. # 6
15 1115-130008-00
BL-EZ30-0815 - 07-28-2019

LIFT LINK ASSEMBLY

Description
DOWN LINK EZ30
SNAP RING FOR SHAFT Ø25
BUSHING
BUSHING
NUT M22×1.5
CONNECTOR
LONG LINK ASSEMBLY
BUSHING
BUSHING
WHEEL BRACKET
BUSHING
BUSHING
SHAFT
ROUND PIN Ø5×35
ROUND PIN Ø5×35
SHAFT
LOAD WHEEL
SHIM
LONG LINK
WASHER
Qty.
Notes
Reqd.
1
2
2 Used up to 02-21-2012
2 Used from 02-22-2012
2
2
2
4 Used up to 02-21-2012
4 Used from 02-22-2012
2
4 Used up to 02-21-2012
4 Used from 02-22-2012
2
Used up to S/N
4
424150330
Used from S/N
424150331
2
2
Not pictured - As
Required - This Shim Is
only used on a few
trucks.
2
You should replace
these shaft roller when
4
replacing part # 1115-
130005-4A (pos. # 8)
12-37
