- Page 1 OPERATOR’S MANUAL STRADDLE LIFT TRUCK Big Lift LLC Manual Part No. 901635 www.bigjoeforklifts.com 08/16/2018...
-
Page 4: Table Of Contents
GENERAL DESCRIPTION ..................5 NAME PLATE AND WARNING DECAL ...............5 LOAD CAPACITY....................8 BEFORE OPERATION ..................9 INSTRUMENTS AND CONTROLS - PDS 20/25/30/40, S22/25/S30....11 INSTRUMENTS AND CONTROLS - PDI, PDM, PDH ........12 OPERATION ......................13 Forward and Reverse Travel and Speed Control .......13 Steering ....................13 Stopping....................14... -
Page 5: Safety Symbols
SAFETY SYMBOLS WARNING and CAUTION are both signal words intended to alert the viewer to the existence and relative degree of a hazard. They are both preceded by a safety alert symbol consisting of an exclamation mark enclosed by a triangle. A Warning indicates a hazard which could result in injury or death if proper pre- cautions are not taken. - Page 6 R6728 PDS 20/25 Name Plate and Warning Decal Locations - Typical R7030 PDS 30/40 Name Plate and Warning Decal Locations - Typical...
- Page 7 R8308 R7031 S22, S25 & S30 Name Plate and Warning Decal Locations - Typical R3965 PDI, PDM & PDH Name Plate & Warning Decal Locations -Typical...
-
Page 8: Load Capacity
WARNING: This truck is equipped with a battery. Read and heed the following warning plus any other warnings located near or on the battery. An example is shown here: R6115 LOAD CAPACITY The further the load center is from the no more than 24 inches from the face of backrest, the lower the load capacity. -
Page 9: Before Operation
Load Center BEFORE OPERATION The table on page 10 covers important motor maintenance and other inspection points on trucks which areas specified in the parts and should be checked prior to operation. service manual maintenance Depending on use, some trucks may section. - Page 10 Operator Checks ITEM PROCEDURE Transmission and hydraulic Check for signs of fluid leakage. systems Forks Check for cracks and damage and that they are properly secured. Chains, cables and hoses Check that they are in place, properly secured and not damaged. Guards and load backrest Check that safety guards are in place, prop- erly secured and not damaged.
-
Page 11: Instruments And Controls - Pds 20/25/30/40, S22/25/S30
INSTRUMENTS AND CONTROLS - PDS 20/25/30/40, S22/25/S30 The steering arm and control handle Detailed operating instructions are in provide controls for steering, forward the Operation section of this manual. and reverse speed control, braking, A battery disconnect is mounted near horn, and raising and lowering the forks. -
Page 12: Instruments And Controls - Pdi, Pdm, Pdh
INSTRUMENTS AND CONTROLS - PDI, PDM, PDH The steering arm and control handle provide controls for steering, forward and reverse speed control, braking, and horn. Control handles on some models have pushbuttons for raising and low- ering the forks, and for an additional "dynamic brake"... -
Page 13: Operation
OPERATION Forward and Reverse Travel and Speed Control R8257 Control Handles All directional and speed controls are to a stop and then, unless the controls located on the control handle. are returned to the center neutral posi- tion, accelerate in the opposite direc- Forward and reverse are controlled by tion. -
Page 14: Stopping
Stopping position when the steering arm is released. Stop the truck as gradually as possible. Unnecessary rapid stopping could be CAUTION: If the control handle does hazardous. Load could become unsta- not raise immediately to ble. the vertical position when released, the truck should You can use plugging to stop the truck, be placed “OUT OF SER-... -
Page 15: Parking
Parking When parking the truck, do not obstruct traffic lanes or aisles. WARNING: Park the truck in its designated Always be sure the load and load parking area. center are within the capacity of Raise the steering arm until verti- the truck. -
Page 16: Moving A Disabled Truck
11. Do not make sudden starts and disturb another load while stops. Operate truck smoothly placing yours in the rack. and gradually. This may cause a danger- ous situation for other opera- 12. Travel slowly squarely tors or pedestrians working in around corners. - Page 17 Do not operate this truck unless you have been trained and authorized to do so, and have read and understand all warnings and instructions contained in this opera- tor’s manual. R6710 Do not operate this truck until you have checked its condition. Give special attention to wheels, horn, lights, battery, controller, lift systems (including forks or attachments, chains, cables and limit switches), brakes,...
- Page 18 Operate truck only from walking position. R3946 Never place any part of the body into the mast structure. R6713...
- Page 19 Do not carry passengers. R3948 Keep feet clear of truck and always wear foot pro- tection R6715...
- Page 20 Observe applicable traffic regulations. Yield right-of-way to pedestrians. Slow down and sound horn at cross aisles and wherever vision is obstructed. R3950 Start, stop, travel, steer and brake smoothly. Slow down for turns and on uneven or slippery surfaces that could cause truck to slide or overturn.
- Page 21 Travel with lifting mechanism as low as possible. Always look in direction of travel. Keep a clear view, and when load inter- feres with visibility, travel with load or lifting mechanism trailing. R6718 Use special care when operating on ramps; travel slowly and do not angle or turn.
- Page 22 Do not overload truck. Check capacity plate for load weight and load center information. R6720 When using forks, space forks as far apart as load will permit. Before lifting, be sure load is centered, forks are completely under load, and load is as far back as possible against load backrest.
- Page 23 Do not handle unstable or loosely stacked loads. Use special care when handling long, high or wide loads to avoid losing the load, striking bystanders or tipping the truck. R6722 Do not handle loads which are higher than the load backrest or load backrest exten- sion unless load is secured so that no part of it could fall backward.
- Page 24 Elevate forks or other lifting mech- anism only to pick up or stack a load. Watch out for obstructions, espe- cially overhead. R6724 Do not lift personnel on forks or work platform with this truck. It is not designed for this function and someone could get seriously injured if they fell off.
- Page 25 Do not allow anyone to stand or pass under a load or lifting mechanism. R6726 When leaving truck neutralize travel control. Fully lower lifting mechanism and set brake. When leaving truck unat- tended also shut off power. R3960...
-
Page 26: Notice - Obtaining A Parts And Service Manual
NOTICE - OBTAINING A PARTS AND SERVICE MANUAL A complete parts and service manual covering this truck is available from Big Lift LLC. To order, obtain the serial number of your truck and contact your Big Joe Authorized Dealer. - Page 28 Big Lift LLC...
