Brushless Motor
Ⅱ
Series
BX
OPERATING MANUAL
Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety precautions.
• Please read it thoroughly to ensure safe operation.
• Always keep the manual where it is readily available.
Table of contents
1 Introduction ..........................................................2
2 Safety precautions ..............................................3
3 Precautions for use .............................................5
4 Preparation ............................................................8
4.1 Checking the product .............................................. 8
4.2 How to identify the product model.................... 8
4.3 Information about nameplate .............................. 8
4.4 Products possible to combine .............................. 8
4.5 Names and functions of parts .............................. 9
5 Installation .......................................................... 10
5.1 Installation location ................................................10
5.2 Installing the driver ................................................10
(sold separately) ......................................................12
(sold separately) ......................................................12
6 Connection ......................................................... 14
6.1 Connection example ..............................................14
6.2 Connecting the power supply (CN1)................15
6.3 Circuit breaker ..........................................................15
6.4 Grounding .................................................................15
6.5 Connecting the motor (CN2, CN3, CN4) .........16
6.7 Connecting the I/O signals (CN5, CN7)............16
devices ........................................................................17
Driver Edition
6.9 Connecting the data setter (CN6) .....................17
7 Operation ............................................................ 19
7.1 Operation by input signals ..................................19
7.2 Test operation (JOG operation) ..........................21
8 Operation panel ................................................ 22
8.1 Names of parts for operation panel .................22
8.2 Main screen transitions .........................................22
9 Maintenance and inspection ....................... 23
9.1 Inspection ..................................................................23
9.2 Warranty .....................................................................23
9.3 Disposal ......................................................................23
10 Protective function .......................................... 24
10.1 Alarm list.....................................................................24
10.2 Warning list................................................................25
11 Specifications ..................................................... 26
12 Regulations and standards ........................... 27
12.1 UL Standards, CSA Standards .............................27
12.2 CE Marking ................................................................27
12.3 Republic of Korea, Radio Waves Act .................27
12.4 RoHS Directive ..........................................................27
(sold separately) ......................................................18
HP-5123
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Oriental motor BXⅡ Driver Edition Series
Summary of Contents for Oriental motor BXⅡ Driver Edition Series
-
Page 1: Table Of Contents
Series Driver Edition OPERATING MANUAL Thank you for purchasing an Oriental Motor product. This Operating Manual describes product handling procedures and safety precautions. • Please read it thoroughly to ensure safe operation. • Always keep the manual where it is readily available. -
Page 2: Introduction
The product described in this manual has been designed and manufactured to be incorporated in general industrial equipment. Do not use for any other purpose. Oriental Motor Co., Ltd. is not responsible for any compensation for damage caused through failure to observe this warning. -
Page 3: Safety Precautions
Safety precautions 2 Safety precautions The precautions described below are intended to ensure the safe and correct use of the product, and to prevent the user and other personnel from exposure to the risk of injury. Use the product only after carefully reading and fully understanding these instructions. - Page 4 Safety precautions CAUTION • Do not use the motor, gearhead, driver, or regeneration resistor in a state where the specification value is exceeded. Doing so may result in fire, electric shock, injury, or damage to equipment. • Do not insert an object into the openings in the driver. Doing so may result in fire, electrical shock, or injury. •...
-
Page 5: Precautions For Use
Precautions for use 3 Precautions for use This chapter covers restrictions and requirements the user should consider when using the product. Be sure to match the output power of the driver with that of the motor when using. Wiring z Connect protective devices to the power line Connect a circuit breaker or earth leakage breaker to the driver power line to protect the primary circuit. - Page 6 Precautions for use Insulation resistance measurement and dielectric strength test z Conduct the insulation resistance measurement or dielectric strength test separately on the motor and the driver Conducting the insulation resistance measurement or dielectric strength test with the motor and driver connected may result in damage to the product.
- Page 7 Precautions for use...
-
Page 8: Preparation
Preparation 4 Preparation This chapter explains the items you should check, as well as the name and function of each part. 4.1 Checking the product Verify that the items listed below are included. Report any missing or damaged items to the branch or sales office from which you purchased the product. Refer to “4.4 Products possible to combine”... -
Page 9: Names And Functions Of Parts
Preparation 4.5 Names and functions of parts This section explains the name and function for each part of the driver. Display Acceleration time potentiometer (ACC) Operation panel Operation keys Internal potentiometer (SPEED) Deceleration time potentiometer (DEC) Input signals connector (CN5) Encoder connector (CN4) Electromagnetic brake connector (CN3) CHARGE LED (Red) -
Page 10: Installation
Installation 5 Installation 5.1 Installation location The motor and driver are designed and manufactured to be incorporated in equipment. Install them in a well-ventilated location that provides easy access for inspection. The location must also satisfy the following conditions: • Inside an enclosure that is installed indoors (provide vent holes) •... - Page 11 Installation z When drivers are installed in a close contact state It is possible to install drivers closely in the horizontal direction. In this case, install the drivers to a flat metal plate offering high heat conductivity [corresponding to an aluminum plate of 350×350×2 mm (13.78x13.78x0.08 in.)]. [30 W, 60 W, 120 W] •...
-
Page 12: Installing The External Potentiometer
Installation 5.3 Installing the external potentiometer (sold separately) Install the external potentiometer PAVR-20KZ (sold separately) as shown in the figure. Variable resistor • Reference mounting hole dimensions Insulation [Unit: mm (in.)] Mounting plate sheet 7.5± (0.30± 0.02 Dial plate Ø3 (Ø0.12) Ø10 (Ø0.39) Set screw (M4) Tightening torque: 0.4 N·m... - Page 13 Installation...
-
Page 14: Connection
Connection 6 Connection This chapter explains how to connect the motor and power supply to the driver. Refer to the USER MANUAL for details. 6.1 Connection example Electromagnetic brake motor (200 W, 400W) Grounding Encoder cable Motor cable Details about setting functions of operation data ⇒... -
Page 15: Connecting The Power Supply (Cn1)
Connection 6.2 Connecting the power supply (CN1) Connect a power supply to the main power supply input terminals (CN1). A power supply cable is not included with the product. Provide a power supply cable separately. Applicable lead wire • Lead wire size: AWG18 to 14 (0.75 to 2.0 mm •... -
Page 16: Connecting The Motor (Cn2, Cn3, Cn4)
Connection 6.5 Connecting the motor (CN2, CN3, CN4) Connect the motor to the driver via the dedicated connection cable (sold separately). Connect the motor power connector of the connection cable to CN2, the electromagnetic brake connector to CN3, and the encoder connector to CN4. When extending the wiring distance between the motor and the driver, use the connection cable (for extension) which is sold separately. -
Page 17: Connecting Analog External Setting
Connection „ CN7 pin assignments „ Pin No. Signal name Function ∗ Analog external setting input OUT0+ Output terminal 0+ [ALM] OUT0− Output terminal 0− [ALM] OUT1+ Output terminal 1+ [MOVE] OUT1− Output terminal 1− [MOVE] OUT2+ Output terminal 2+ [WNG] OUT2−... -
Page 18: Connecting The Regeneration Resistor
Connection 6.10 Connecting the regeneration resistor (sold separately) If vertical drive (gravitational operation) such as elevator applications is performed or if sudden start-stop operation of a large inertia is repeated frequently, use the regeneration resistor EPRC-400P (sold separately) or RGB100 (sold separately). -
Page 19: Operation
Operation 7 Operation Ⅱ Four control modes are provided in the BX Series. This chapter explains two operating methods that the motor can be operated immediately in the speed control mode (factory setting). • Operation by input signals • Test operation (JOG operation) Refer to the USER MANUAL for other control modes and how to use in details. - Page 20 Operation „ Setting the operating speed „ Set the operating speed of the motor using the internal potentiometer (SPEED), analog external setting devices, or operation keys of the operation panel. This section explains how to set the speed using the internal potentiometer and analog external setting devices.
-
Page 21: Test Operation (Jog Operation)
Operation 7.2 Test operation (JOG operation) Simply connecting a power supply, motor, and driver can perform JOG operation. Using JOG operation, the connection between the motor and the driver can be checked. „ Operating method (Speed control mode) „ This section explains the procedure to operate in the speed control mode. 1. -
Page 22: Operation Panel
Operation panel 8 Operation panel 8.1 Names of parts for operation panel The operation panel cannot be removed from the driver. Display Displays operation data or parameters. 【SET】 key 【MODE】 key 【 】 【 】 keys • Determines the data. •... -
Page 23: Maintenance And Inspection
It is recommended that periodic inspections would be conducted for the items listed below after each operation of the motor. If an abnormal condition is noted, discontinue any use and contact your nearest Oriental Motor sales office. • Conduct the insulation resistance measurement or dielectric strength test separately on the motor and the driver. -
Page 24: Protective Function
Excessive current was flown through the driver Overcurrent due to ground fault, etc. when the power has been cycled, contact your nearest Oriental Motor sales office. • The power supply voltage exceeded • Check the voltage of the main power approximately 120% of the rated voltage. -
Page 25: Warning List
Protective function Alarm code Alarm type Cause Remedial action • Check the connection for the thermostat output and the TH input of • The regeneration resistor is not connected the regeneration resistor. properly. • The power consumption of the • The regeneration resistor was overheated Regeneration resistor regeneration resistor exceeds the extraordinarily. -
Page 26: Specifications
Specifications 11 Specifications „ Specifications „ The value in a state where the gearhead is not combined is described in each specification for the rated torque, maximum instantaneous torque, and rated speed. For motor models, refer to the operating manual included with the motor. z 30 W, 60 W Motor BXM230... -
Page 27: Regulations And Standards
Regulations and standards 12 Regulations and standards This product is recognized by UL under the UL and CSA standards, and also affixed the CE Marking under the Low Voltage Directive and the EMC Directive. 12.1 UL Standards, CSA Standards Applicable Standards Certification body Standards File No. - Page 28 • Unauthorized reproduction or copying of all or part of this manual is prohibited. If a new copy is required to replace an original manual that has been damaged or lost, please contact your nearest Oriental Motor branch or sales office.
