OPERATING MANUAL
Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety precautions.
• Please read it thoroughly to ensure safe operation.
• Always keep the manual where it is readily available.

Table of contents

1
Introduction ......................................................... 2
2
Safety precautions ............................................. 3
3
Precautions for use ............................................ 5
4
Checking the product ....................................... 7
4.1 Package contents .................................................... 7
4.2 Combination tables ................................................ 7
4.3 Information about nameplate ............................ 8
(sold separately) ....................................................... 8
4.5 Names of parts ......................................................... 9
5
Installation ..........................................................10
5.1 Installation location ..............................................10
5.2 Installation method ..............................................11
permissible axial load ..........................................13
6
Connection .........................................................14
connection cable ...................................................15
6.3 Detaching the connection cable .....................15
6.4 Caution about wirings .........................................15
7
Grounding ...........................................................16
8
Inspection and maintenance .......................17
8.1 Inspection ................................................................17
8.2 Warranty ...................................................................17
8.3 Disposal .....................................................................17
9
Specifications .....................................................18
9.1 Specifications ..........................................................18
9.2 General specifications ..........................................18
10 Regulations and standards ...........................19
HM-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Oriental motor BLM

  • Page 1: Table Of Contents

    HM-5303 Brushless Motor BLM Motor Connector Type Watertight, Dust-Resistant OPERATING MANUAL Thank you for purchasing an Oriental Motor product. This Operating Manual describes product handling procedures and safety precautions. • Please read it thoroughly to ensure safe operation. • Always keep the manual where it is readily available.
  • Page 2: Introduction

    Operating manuals are not included with the product. Download from Oriental Motor Website Download Page or contact your nearest Oriental Motor sales office. Operating manual name Motor BLM Motor Connector Type Watertight, Dust-Resistant OPERATING MANUAL (this document) BMU Series OPERATING MANUAL Driver BLE2 Series OPERATING MANUAL Refer to the operating manuals of the speed controller for details about connections and operations.
  • Page 3: Safety Precautions

    Safety precautions Safety precautions The precautions described below are intended to prevent danger or injury to the user and other personnel through safe, correct use of the product. Please read and understand these precautions thoroughly before using the product. WARNING Handling the product without observing the instructions that accompany a "WARNING"...
  • Page 4 Safety precautions CAUTION • Do not use the motor beyond the specifications. Doing so may result in fire, electric shock, injury or damage to equipment. • Do not touch the motor while operating or immediately after stopping. The surface of the motor is hot and it may cause a skin burn(s).
  • Page 5: Precautions For Use

    Precautions for use Precautions for use This chapter covers restrictions and requirements the user should consider when using the product. Be sure to match the motor output power with the driver output power. „ Wiring z Connecting the motor and driver To connect the motor and driver, always use the dedicated connection cable (sold separately).
  • Page 6 Precautions for use About watertight performance The motor conforms to IP67 rating for degree of protection in a state where the connection cable is attached. (Except for the end part of the driver side including the connector for driver connection of the connection cable) Use the motor after thoroughly reading the following if the motor is washed with water or used in an environment where water is splashed.
  • Page 7: Checking The Product

    Checking the product Checking the product Package contents Verify that the items listed below are included. Report any missing or damaged items to the branch or sales office from which you purchased the product. Verify the model number of the purchased product against the number shown on the nameplate. „...
  • Page 8: Information About Nameplate

    Checking the product Information about nameplate The figure shows an example. The position describing the information may vary depending on the product. „ Motor Motor model Motor speci cations Manufacturing date Serial number „ Gearhead Gearhead model Manufacturing date Serial number Connection cable/flexible connection cable (sold separately) To connect the motor and driver, the dedicated connection cable (sold separately) is needed.
  • Page 9: Names Of Parts

    Checking the product Names of parts The figure shows the gearhead pre-assembled. Connector for cable connection Output shaft Motor Mounting holes Gearhead (4 places) „ Connection cable/flexible connection cable (sold separately) Ground terminal Connector for Power connector (white) motor connection Sensor connector (black) Connectors for driver connection...
  • Page 10: Installation

    Installation Installation This section explains the installation method of a load in addition to the installation location and installation method of the product. Installation location Install the product in a well-ventilated location that provides easy access for inspection. The location must also satisfy the following conditions: •...
  • Page 11: Installation Method

    Installation Installation method „ Assembling the gearhead to the motor 1. Keep the pilot sections of the motor and gearhead in parallel, and assemble the gearhead with the motor while slowly rotating it clockwise/counterclockwise. At this time, note so that the motor output shaft does not hit the side panel or gears of the gearhead strongly. Side panel Motor output shaft Pilot section...
  • Page 12 Installation „ Installation method Secure the motor through four mounting holes using the gearhead included mounting screw set. Do not leave a gap between the motor and mounting plate. Plain washer Spring washer Make the installation hole larger than the external Hexagonal socket dimension of the product +1 mm (0.04 in.).
  • Page 13: Permissible Radial Load And Permissible Axial Load

    Installation Permissible radial load and permissible axial load Make sure a radial load and axial load applied to the output shaft will not exceed the permissible values shown in the table below. Note Failure due to fatigue may occur when the bearings and output shaft are subject to repeated loading by a radial or axial load that is in excess of the permissible limit.
  • Page 14: Connection

    Connection Connection Connecting the motor and driver Connect the motor and driver using the connection cable (sold separately). There are three types of connection cables which cable outlet directions are different. Up to two pieces of the connection cables for relay can be connected. Check the operating of the driver.
  • Page 15: Connection Procedures Of The Motor And Connection Cable

    Connection Connection procedures of the motor and connection cable The following example explains using the connection cable of "cable outlet in output shaft direction." Remove Connector cap Attach Check the cable outlet direction and insert the connector securely. Position of locking lever The connector cannot be inserted Locking lever if the locking lever is turned down.
  • Page 16: Grounding

    Grounding Grounding Ground using the Protective Earth Terminals of the motor and driver, as well as the ground terminal of the connection cable. Check the operating manual of the driver for how to ground. Note Be sure to ground the motor and driver. Failure to do so may result in electric shock or damage to the product. Static electricity may cause damage to the product if the Protective Earth Terminals are not grounded.
  • Page 17: Inspection And Maintenance

    Inspection and maintenance Inspection and maintenance Inspection It is recommended that periodic inspections would be conducted for the items listed below after each operation of the motor. If an abnormal condition is noted, discontinue any use and contact your nearest Oriental Motor sales office. Note Do not conduct the insulation resistance measurement or dielectric strength test with the motor and speed controller connected.
  • Page 18: Specifications

    Specifications Specifications Specifications Check on the Oriental Motor Website for the product specifications. General specifications Ambient 0 to +40 °C [+32 to +104 °F] (non-freezing) temperature Ambient 85% or less (non-condensing) Humidity Altitude Up to 1000 m (3300 ft.) above sea level No corrosive gas or dust.
  • Page 19: 10 Regulations And Standards

    Regulations and standards 10 Regulations and standards Check on the Oriental Motor Website for the regulations and standards. „ UL Standards, CSA Standards This product is recognized by UL under the UL and CSA Standards. „ CE Marking This product is affixed with the marks under the following directives. z Low Voltage Directive Installation conditions •...
  • Page 20 Tel:1800-806-161 4-8-1 Higashiueno, Taito-ku, Tokyo Technical Support Tel:00 800/22 55 66 22 110-8536 Japan Tel:+81-3-6744-0361 Tel:1800-888-881 www.orientalmotor.co.jp/ja Unit 5 Faraday O ce Park, Rankine Road, Basingstoke, Hampshire RG24 8QB UK Tel:1800-120-1995 (For English) Tel:+44-1256347090 1800-121-4149 (For Hindi) Tel:+33-1 47 86 97 50...
