- Page 1 Package Included: 1PC X Scanner; 1PC X 2.4G USB Receiver; 1PC X USB Cable; 1PC X Quick Setup Guide Note: This is a general manual. If you need a full manual please download it from our of�icial website: www.gzxlscan.com...
-
Page 2: Product Information
Product Information Scanning Window Module Power Button (On/Off) Battery Light/Read Indicator Light (Green/Blue/Red) Trigger button Bluetooth Light/Read Indicator Light (Blue/White) Beeper Lanyard Eyelet Pin for charging... -
Page 3: Firmware Version
Firmware version will be displayed by scanning “$SW#VER”. Firmware Version: $SW#VER Netum barcode scanners are factory programmed for the most common Barcode Programming terminal and communications settings. If you need to change these settings, programming is accomplished by scanning the bar codes in this guide. An asterisk (*) next to an option indicates the default setting. - Page 4 Get Started: Plug the USB dongle on your computer. If you use US keyboard, Working Via USB Dongle (Wireless Mode) it's plug and play. If you use other type of keyboard , please refer to "keyboard language" to con�igure the keyboard language before use it. %#IFSN0$1 *Wireless Transmit Get Started: Scan “Working via Bluetooth”,pairing the bluetooth.
- Page 5 If you want to shift from HID to SPP or BLE just scan the Corresponding Important Notes: command barcode. If you want to shift from SPP or BLE to HID mode, �irst ignore (or delete) "Netum Bluetooth"→ turn off bluetooth→ scan command barcode of HID→ Open the bluetooth → re-pair it.
- Page 6 By scanning the appropriate barcode below will change the bluetooth Transmission Speed Via Bluetooth Connection transmit speed. AT+HIDDLY=4 AT+HIDDLY=10 High Speed *Medium Speed AT+HIDDLY=25 Low Speed When you plug the USB dongle to your device, USB HID-KBW feature will be USB DONGLE AS HID-KBW enabled by default.
- Page 7 USB DONGLE AS VIRTUAL COM If you connect scanner to the Host via USB dongle, by scanning “USB COM USB COM Port Emulation Port Emulation” will allow your device to receive data in the way as a serial port does. $USB#COM USB Dongle as Virtual COM When scanner is connected to your device via USB cable , USB HID-KBW...
- Page 8 For example If you use French Keyboard, scan command barcode of “French Keyboard Language keyboard ”. If you use a US keyboard you can ignore this step. $LAN#EN $LAN#FR *America EN keyboard French keyboard $LAN#GE $LAN#IT Germany keyboard Italy keyboard $LAN#PT $LAN#ES Portugal keyboard...
- Page 9 $LAN#TK $LAN#TF Turkey Q keyboard Turkey F keyboard Working Mode If you are heading for a working area which lies outside the Bluetooth signal range, you may activate scanner’s store mode, following steps described below. Under this mode, all scanned data will be stored directly into the buffer memory of the device.
- Page 10 Time period set for scanner from idle to sleep Idle Time $POWER#OFF $RF#ST00 Power Off 0 Min $RF#ST20 $RF#ST60 10Mins 30Mins Convert Case * Disable Convert Case Up Low Case Swap (A<->a) All Upper Case (a->A) All Lower Case (A->a)
-
Page 11: Beep Volume
Beep Volume By scanning the appropriate barcode below will change the beep volume. $BUZZ#1 $BUZZ# *High Volume Low Volume $BUZZ#0 Mute Function Key Mapping When Function Key Mapping is enabled, function characters are sent over the keypad. $KEY#MO $KEY#M1 *Disable Function Key Mapping Enable Function Key Mapping (10) - Page 12 LED Activity/Beep Pattern/Indication under different Connections 2.4G RF Wireless Connection Bluetooth LED Activity Beep Pattern Read indicator LED Activity (Square Shape) Indication Working Mode No beep Sleeping /Power OFF Blue LED ON and then OFF Beep Once Blue LED ON and then OFF Wake up from Sleep Mode White LED ON and then OFF Beep Once Blue LED ON and then OFF...
- Page 13 1. Some barcodes cannot be read, why ? a. Dirty or unclear barcodes might not be read. b. The possible reason is that setting for some barcode types not commonly used is off by default. You need to activate a speci�ic barcode type to get it to work.
-
Page 14: Contact Information
Please do not hesitate to contact us if you need any other con�igurations. Note: Contact Information For customization or price inquiry: Tel. +86-20-6626-0708 Whatsapp: +86-188-2626-1132 Email: netum004@gzxlscan.com Website: www.gzxlscan.com For aftersales service: Tel. +86-20-6626-0708 Whatsapp: +86-188-2626-1132 Email: service@gzxlscan.com Website:wwwgzxlscan.com Unit 137, The Paci�ic Industry Park, Xintang Town,Zengcheng District, Guangzhou, China/511340...
