Page 1
If you want to have other configurations please refer to below programming barcodes. Barcode Programming Netum barcode scanners are factory programmed for the most common terminal and communications settings. If you need to change these settings, programming is accomplished by scanning the bar codes in this...
Page 2
2) Touch Home | Menu | Settings | Wireless & Networks | Bluetooth settings 3) Make sure the device has Bluetooth “On”. Scan for devices. 4) In the list of found devices, select “Netum Bluetooth”. Tap Pair. 5) The scanner will connect to the Android device.
Page 3
Click on “Bluetooth” in the left column. Your IOS device will automatically start searching for any Bluetooth Devices in the area. 3) Once you have identified the “Netum Bluetooth” on the screen, tap on it and you will automatically be connected. The scanner’s LED light will turn to solid blue.
Page 4
American Keyboard * Portugal Keyboard French Keyboard Spanish Keyboard Germany Keyboard Turkey Q Keyboard Italy Keyboard Turkey F Keyboard B) Application Mode (SPP) For Android or Windows only Software installation is required, If you have an application that supports mobile scanners this is the mode recommended. BT SPP Mode Note: this command is only apply for Bluetooth Wireless Mode...
Page 5
Scan Mode Trigger Mode (Default) Scanning this bar code will enable the scanner to enter manual trigger mode. Continuous Mode This mode enables the engine to scan/capture, decode and transmit over and over again. Auto Sense Mode Scanning this bar code will enable the scanner to enter auto sense mode. Working Mode If you are heading for a working area which lies outside the signal range, you may activate the offline mode of the scanner, following the steps described below.
Page 6
Clear Memory 3).By scanning the following barcode, all data entries in the buffer memory can be manually uploaded after reconnecting to the working station (only in offline mode). Uploading the Data 4). By scanning the following barcode, the gross quantity of the uploaded data entries will be summarised (only in offline mode).
Page 7
Idle Time Scanner will stay awake during the idle time that you set for it and turn to sleep if you haven't used it during the whole idle time. 30 s 6 Mins 12 Mins Mins 1Hour 2Hours IOS Keyboard POP UP/HIDE During the scanning IOS keyboard can be hided or popped up by scanning below command barcode.
Page 8
Restore factory default Scanning the following barcodes one by one to restore the scanner to factory defaults. (Four steps included) 1. Factory Restore 2. Serial Port 3. Baud Rate 19200 4. Enter+LF...
Page 9
Common function Barcodes Enable/Disable UPC-E 1000021 1000020 *Enable UPC-E Disable UPC-E Enable/Disable EAN-8 1000041 1000040 *Enable EAN-8 Disable EAN-8 Enable/Disable EAN-13 1000031 1000030 *Enable EAN-13 Disable EAN-13 Enable/Disable Bookland EAN(ISBN) 1000231 1000230 Enable Bookland EAN *Disable Bookland EAN Decode UPC/EAN Supplementals UPC/EAN Supplementals are bar codes appended according to specific format conventions (e.g.UPC A+2, UPC E+2, EAN 13+2, EAN 13+5).
Page 10
• Only read the barcode with supplementals- The scan engine can only read the barcode with supplementals. 2010E01 Decode UPC/EAN with Supplementals • Auto read supplementals- The scan engine can not only read the barcode with supplementals,but also read the barcode without supplementals. 2010E02 Auto discriminate UPC/EAN Supplementals Eable/Disable Code 128...
Page 13
Support For any inquiries concerning our products, please send an email to service@gzxlscan.com, and we will respond to you as soon as possible. Contact Information Tel.:+0086 20-6626-0708 Email:service@gzxlscan.com Addr.:Unit 137, The Pacific Industry Park, Xintang Town,Zengcheng District, Guangzhou,China/511340 Made in China...
