- Page 1 Soliris Notice Brugsanvisning Instructions Käyttöopas Anleitung Bruksanvisning Handleiding Veiledning Manuale...
-
Page 3: Table Of Contents
Soliris io TRANSLATED VERSION These instructions apply to all versions of Soliris io, the different models of which are available in the current catalogue. CONTENTS 1. Introduction 3. Use and maintenance 1.1. Field of application 3.1. Wind, Sun and Rain functions 1.2. -
Page 4: Liability
Somfy’s instructions and the applicable regulations in the country of installation. Any operation of the Soliris io sensor outside the scope of application described above is prohibited. Such use, and any failure to comply with the instructions given in this guide, absolves Somfy of any liability and invalidates the warranty. -
Page 5: Soliris Io In Detail
(H) to the wall using the screws (C) supplied. 2.3. WIRING 2.3.1. Soliris io wiring Attention Perform disassembly and wiring operations away from any dust, moisture or foreign bodies to maintain tightness. Copyright 2019-2020 SOMFY ACTIVITES SA, Société Anonyme. All rights reserved. ©... - Page 6 9] Screw the front panel (N) of the mounting bracket back on. Attention Tighten the screws completely to maintain the tightness of the mounting bracket. To complete the installation, go to section 2.4. Copyright 2019-2020 SOMFY ACTIVITES SA, Société Anonyme. All rights reserved. ©...
- Page 7 8] Screw in the metal tab (W): the cable must be fed under the tab. 230V RAIN ≥2mm Attention ≥2mm The cable sheath must exceed the tab by at least 2 mm. Copyright 2019-2020 SOMFY ACTIVITES SA, Société Anonyme. All rights reserved. ©...
-
Page 8: Fitting The Protective Housing
• In comfort mode, when the rain sensor detects rain : - If it is paired with a Somfy io bi-directional control point (e.g. TaHoma), via Soliris io, follow the instructions for this control point. - Otherwise, the motorised product goes to its lower end limit. This mode serves, for example, to protect users from the rain under their awning. - Page 9 The Soliris io sensor is paired. To pair the Soliris io sensor with other io motors or receivers, repeat this procedure. To pair using an io-homecontrol® control point from a partner brand or a Somfy io bi-directional control point (e.g. TaHoma), please refer to the relevant guide.
- Page 10 • Turn the potentiometer towards the (-) sign to decrease the sensitivity threshold: the sun must shine less brightly to cause the motorized product to lower. Copyright 2019-2020 SOMFY ACTIVITES SA, Société Anonyme. All rights reserved. ©...
-
Page 11: Tips And Advice On Installation
1] Switch off the mains power supply. 2] Loosen the screws located on the protective housing G) and unclip the protective housing (G) from the mounting bracket (H). 90° STOP Copyright 2019-2020 SOMFY ACTIVITES SA, Société Anonyme. All rights reserved. ©... - Page 12 The procedure to be followed to unpair Soliris io from an io receiver or motor is identical to the pairing procedure, see 2.5.1. 2.6.4. Replacing a broken or faulty Soliris io 1] Press the PROG button on the Somfy io local control point until the motorised product performs an up-and-down movement (≈ 2 s).
-
Page 13: Use And Maintenance
Moves to the lower end limit (or my) position automatically and remains blocked as long as the sensor detects rain. If the sensor is paired with a Somfy io bi-directional control point (e.g. TaHoma ), the scenario programmed by the user is activated. -
Page 14: Behaviour Of The Motorised Product According To Climatic Conditions
Wind function then Sun function, see 3.1. 3.2.2. Wind, Sun and Rain in Safety mode or Comfort mode ͉ ͉ When a rain sensor is connected to the Soliris io sensor and the mode is selected. Priority of functions Priority of functions Climatic conditions... -
Page 15: Questions About The Product
Wait until the sensor has not inhibiting the Sun function. detected any wind and unlock the motorised product. The motorised product rises The sensor is not operating. Contact an installer. once an hour. Copyright 2019-2020 SOMFY ACTIVITES SA, Société Anonyme. All rights reserved. ©... -
Page 16: Technical Data
Unlimited Type-1 automatic action device. For more information about the technical data relating to this product, please contact a Somfy representative. We care about our environment. Do not dispose of the appliance with the household waste. Take it to an approved collection point for recycling. - Page 17 SOMFY ACTIVITES SA 50 avenue du Nouveau Monde F-74300 Cluses www.somfy.com 5151207B...
