EN
3.
LOCATION OF INSTALLATION
Before proceeding with the installation of the equip-
ment agree the location with the client, taking into ac-
count the following points:
1.
T he base must be able to support the weight of the
unit.
2.
T he safe distances between the unit and other
equipment or structures must be strictly respected
to ensure the intake and outlet air is free to circu-
late.
3.
T he equipment must be installed by a competent
and qualified technician, in compliance with the
applicable national legislation of the country of
destination, respecting the required minimum
maintenance access spaces.
4.
POSITIONING
•
Before lifting the unit verify the lifting capability
of the equipment being used, taking into account
the information provided with the packaging.
•
When lifting insert through the unit's base holes
lifting bars (NOT PROVIDED) of sufficient length
to locate the lifting chains and safety lugs.
•
Position the unit in the place indicated by the
client, inserting between the unit's base and
the base support a rubber pad (minimum 10
mm thick) or anti-vibration mounts. For further
information refer to the dimensional tables.
•
Secure the unit and ensure it is level; check that
sufficient access is provided for hydraulic and
electrical connections.
•
In the case of installation where gusts of wind
may occur adequately secure the unit using ap-
propriate ties.
WARNING:
If the unit is installed in particularly windy
locations the provision of wind barriers
may be necessary to avoid malfunctions.
6
WARNING:
Lifting bars are NOT provided.
ANL / 290-650
18.03. 5719210_03
