ANL / 290-650
7.5. ANL [C] 290-300-340-400 (mm)
191
7.6. ANL [C] 580-620-650 (mm)
189
18.03. 5719210_03
A
B
184
152
233
C
D
183
138
219
A Inlet - Intake line
189
B
Liquid line
Otlet -
C Inlet - Intake line
Liquid line
D Otlet -
EN
C
Ø 35
D
183
Ø 22
138
219
Ø 42
Ø 28
17
