7.2. DIMENSIONS ANL [ ° ] 400 (mm)
1605
2450
7.2.1. MAXIMUM OVERALL (mm)
200 2050
Ø 16
Ø 16
1735
200 2050
2525
7.2.2. LIFTING POINTS (mm)
Ø 40
800
420 1610
800
7.2.3. POSITION ANTI-VIBRATION MOUNTS (mm)
200 2050
Ø 16
Gy
Ø 16
A
Gx
200 2050
B
14
1100
200
Ø 16
Ø 16
200
3000
Ø 40
420
800
1100
200
Ø 16
Ø 16
C
200
D
1605
2450
1735
1160
2525
7.2.4. MINIMUM CLEARANCE SPACE (mm)
800
800
Gy
A
Gx
B
ANL / 290-650
WARNING
The unit is supplied mounted on a
pallet. To lift with a forklift or chains
utilise lifting bars (NOT PROVIDED).
WARNING
The units cannot be stacked.
