- Page 1 Core Health & Fitness 8/10-Series PVS Assembly MANUAL...
- Page 2 8/10-Series PVS Install Instructions Applies to: 8/10-Series PVS Tools Required*: • #2 Phillips Screwdriver • 5mm Allen Key *Please note that some additional tools will be required for HDMI cable routing. Route the HDMI cable through the machine, before beginning the PVS installation. See below for routing paths: 8-FC 8-RB...
- Page 3 8-VS 8-CT 8-TR(x) 8-RDE 10-TRx Page 2...
- Page 4 Please note that while the images below show a PVS installation onto a treadmill, the steps are valid for ALL units. Use a Phillips screwdriver to remove the screws securing the front of the console to the console rear shroud. Take note of console connections, disconnect wiring from mast to console, and remove console front.
- Page 5 Use a 5mm allen key to secure the PVS bracket to the console mast using four (4) M8 x 20mm screws. Connect black/white power cable from mast to red/black cable from the PVS bracket then connect the male 3.5mm audio jack from the mast to the female 3.5mm audio jack extension from the PVS bracket.
- Page 6 Reinstall Back PVS Shroud and align the PVS grommet. To install the controller, remove the front of the console, then use a #2 phillips screwdriver to remove the screw securing the blank cover to the console. Replace the blank cover removed in Step 6 with the PVS controller then secure using the same screw removed in Step 6.
- Page 7 Reinstall the front of the console. For units with Gen 1 hotbar, go to Page 7 to continue installation. For units with Gen 2 hotbar, go to Page 9 to continue installation. For units without a hotbar, go to Page 11 to continue installation. Page 6...
- Page 8 Headphone Jack - Units with Gen 1 Hotbar For Star Trac treads 8-TRx, 8-TR, 8-TC, and the Stairmaster 8-G Stepmill after installing the PVS, you must install the headphone jack in the hotbar. The following steps must be completed after primary installation of the PVS and controller.
- Page 9 Remove the 2 Phillips screws on the USB panel and remove the panel from the console. Disconnect the USB cable from the USB board. Connect the USB cable and HDMI cable to the new panel, apply the overlay to the panel, then reinstall panel into the console.
- Page 10 Headphone Jack - Units with Gen 2 Hotbar Connect the headphone cable from the PVS (3) to the hot bar cable. Use a #2 phillips screwdriver to remove the PCB- from the Gen 1 hotbar insert, then install it into Gen 2 hotbar insert.
- Page 11 Remove the 2 Phillips screws on the USB panel and remove the panel from the console. Discon- nect the USB cable from the USB board. Connect the USB cable and HDMI cable to the new panel, apply the overlay to the panel, then reinstall panel into the console.
- Page 12 Headphone Jack - Units without Hotbars For units without hot bars including the 8G, 8-UB, 8-RB, the following steps must be completed after primary installation of the PVS and controller. The headphone jack goes directly into the console with a new bar replacing the existing USB/HDMI bar. Use a #2 phillips screwdriver to remove the two screws from original USB panel, remove the panel, then disconnect the USB cable from the...
- Page 13 To Panel Connect the straight side of the same cable to the 3.5mm audio cable (3) from the screen. Carefully close the console and refer to the owner’s manual for programming and operation instructions. From Screen Page 12...
- Page 14 © 2019 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8373, REV D...
