- Page 1 CORE HEALTH & FITNESS 8CT CROSS TRAINER OWNER'S MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ........................3 IMPORTANT LABEL LOCATIONS ........................4 PRODUCT SPECIFICATIONS ........................4 ASSEMBLY ........................5 ................5 REQUIRED TOOLS ASSEMBLY HARDWARE ..............5 PROCEDURE ..............6 OPERATION LED CONSOLES ........................11 MAINTENANCE MODE ..............13 MAINTENANCE ........................17 REPLACEMENT PARTS ........................18 9-6170-XXXXP0 - 8CT .............. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING! Before using this product, it is essential to read the ENTIRE Owner’s Manual and ALL installation instructions. The Owner’s Manual describes equipment operation and instructs members on how to use correctly and safely. Read all warnings posted on the machine. Health related injuries may result from incorrect or excessive use of exercise equipment. -
Page 4: Important Label Locations
“Danger" labels that are illegible or damaged. For service and support call 1 (888) 678-2476 or visit https://connect.corehandf.com 050-6023 731-0512 050-5929 050-2215 LABEL, STAR TRAC, 139mm X STICKER, CAUTION, PINCH POINT START STOP, LED DISPLAYS LABEL, GENERAL WARNING, 32.5mm ICON E-TBT 050-6022 190mm, EXTRUDE DECAL, STAR TRAC Shipping Weight (Boxed): 432.1 lbs (196 kg) -
Page 5: Assembly
ASSEMBLY REQUIRED TOOLS • Torque Wrench • 4mm, 6mm Allen Socket • 13mm Socket • Ratchet Wrench • #2 Phillips Screwdriver • 19mm Open-Ended Wrench Parts Included In the Box: # PN Description A 170-0739 ASSEMBLY WIRE PULL TOOL B 721-1650-XX KIT, TOOL, INSTALL, 8-CT, BLK C 620-9131 OWNERS MANUAL, 8-CT, 9-6170-XXXXP0... -
Page 6: Procedure
PROCEDURE 1. Level the Rear Platform (721-1649-XX) of the machine by using a 19mm open-end wrench to adjust the four Leveling Feet (740-7023) and four Hex Nuts (740- 721-1649-XX 7173). 740-7173 740-7023 Fig. 5 2. Align Left Swing Arm (721-1618-XX) over the Pivot Arm (740-7751-XX) of the user’s left side. - Page 7 170-0739 4. Route the cable bundle using the Cable Pull Tool (170-0739) through the Beauty Ring (721-1428- XX) and up through the Mast (721-1611-XX). 721-1611-XX 5. After the wire bundle has been routed successfully through the mast, remove and discard the cable pull tool. Note: Do not use a knife or blade as this may 721-1428-XX damage the wiring.
- Page 8 8. Remove the Rear Mast Shroud (721-1612) by removing three Phillips Head Machine Screws (110-4480) and set aside. 110-4480 721-1612 Fig. 10 9. Unpackage the console and firmly pull the rear console cover off from the bottom. 10. Place the front of the console against the console weldment, angled forward.
- Page 9 11. Drape all wires from the base out the back of the mast weldment prior to installing the console. 12. Use a torque wrench with a 10mm socket to secure the console to mast weldment with four screws 110-4447 as shown in Fig. 11. TORQUE TO 7.4-11 ft-lbs (10-15 If installing a PVS kit or 800/900 MHz controller, please refer to the...
-
Page 10: First Time Setup
FIRST TIME SETUP SELECT THE MODEL 1. Press and hold the 1, 2 on the left keypad and the 8 key on the right keypad together 2. A beep will sound and “MAINTENANCE MODE” will display momentarily in the Information Window. 3. -
Page 11: Operation Led Consoles
Self-Powered Product: Star Trac Electronic Bikes and Ellipticals as well as StairMaster FreeClimbers with LED console are often used in facilities in a self-powered state. This wireless charging tray is designed to charge mobile phones on these self-powered products. Some limitations may apply. -
Page 12: Display Measurements
Display Measurements Message Window The top display window includes several measures: Current total workout time TIME Total distance traveled in mile or DISTANCE Current HR in beats per minute, HEART RATE if available Current total calories CALORIES Progress Window & Track Shows a graphic representation of elevation during a program. -
Page 13: Maintenance Mode
MAINTENANCE MODE Maintenance Mode allows access to service and diagnostic information, as well as provides the ability to adjust certain program default parameters. To enter Maintenance Mode: 1. Press and hold the 1, 2 on the left keypad and the 8 key on the right keypad together. 2. -
Page 14: Manually Updating Firmware
A complete list of the items that you may display and change in Maintenance Mode: Highest Highest Item Lowest Value Default Notes Item Lowest Value Default Notes Value Value SYSTEM CALIBRATION DISP V0.3.1 (1) SPD CAL 00.09 (02) ELV CAL Elevation calibration function V2.3.5 EXIT... -
Page 15: Fcc Warning
FCC INFORMATION & INDUSTRY CANADA WARNING FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Text Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -
Page 16: Ic Radiation Exposure Statement
(ii) for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the bands 5250- 5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with the e.i.r.p. limit; pour les dispositifs munis d’antennes amovibles, le gain maximal d’antenne permis pour les dispositifs utilisant les bandes de 5 250 à... -
Page 17: Maintenance
MAINTENANCE TOOLS Working on this product will require basic and/or sometimes specialty tools based on the type of service that will be performed at any time. To assist, we recommend having the tools listed available when performing maintenance. • Metric Allen Key Set •... -
Page 18: Replacement Parts
LABEL, GENERAL WARNING, 8 BCVS FC 731-0120 SCREW, M8 X 1.25, 20MM, FHM.HK 050-6022 190mm, EXTRUDE DECAL, STAR TRAC 731-0350 Screw, M10X1.5, 25mm, SHC, HK 050-6023 LABEL, STAR TRAC, 139mm X 32.5mm 731-0363 NUT,M10X1.5,NYLOC 110-3129 NUT, 5/16-32X .06 THK, HEX PNL 731-0367 WASHER,PLAIN,M10 110-3373 Screw, M10x1.5, 85mm, SHC, HK, AS, NKL, Gr-10.9... - Page 19 721-1619 110-3671 731-0411 721-1617-XX 740-4589 120-3547 740-7922 721-1618-XX 740-4593 740-4591 721-1611-XX 721-1428-XX 110-3676 Fig. 21 Upper Swing Arms Fig. 22 Mast 721-1660-XX 721-1619 050-6022 720-5319 050-2215 721-1659-XX 140-3323 110-4480 740-7730-XX 721-1612 740-7897 740-7844-XX 720-5318 740-7845-XX 721-1646-XX 110-3750 740-7843-XX 170-0729 721-1621 721-1623 HR Grips and Cupholders Front Shrouds...
- Page 20 050-2214 721-1649-XX 240-6933 220-0388 721-1657 050-2051 220-0372 740-9306 140-3588 120-3038 740-7955 110-3129 740-7807 740-7897 Fig. 25 Connection Base Plate Fig. 26 Step Platform 120-3354 731-0350 740-4589 740-7751-XX 740-4591 740-7173 110-3524 130-1694 740-7023 Fig. 27 Feet and Wheels Fig. 28 Pivot Arms Page 20...
- Page 21 721-1662 731-0120 740-9272 110-3621 120-3364 740-8470 740-7802 130-1846 721-1639-XX 740-7895 740-8725 721-1637 740-7826-XX 740-7162 740-9290-XX 731-0570 721-1654-XX 740-8467 721-1653 740-7183 740-8468 721-1641-XX 740-8469 050-6023 731-0512 740-9286-XX 120-0480 731-2894 721-1496 740-8475 740-7846 731-0363 Fig. 29 Pedals Fig. 30 Beam Legs 740-9108 740-9322-XX 110-3373 740-9290-XX...
-
Page 22: 700-0549-Xx - Display Led, Bcs
260-0986 718-1127 718-5067 440-0280 110-3763 740-7896 740-7898 717-0380 740-9281 140-3418 731-0373 721-1045 731-0367 731-1363 731-0363 Fig. 33 Tensioner and Generator Fig. 34 Battery and Lower Control Board 700-0549-XX - DISPLAY LED, BCS Part Number Description 050-5929 START STOP, LED DISPLAYS 050-5937 KEYPAD, NAV BAR, LED DISPLAYS 050-5951... -
Page 23: Support & Service
SUPPORT & SERVICE CORE CONNECT Core Connect is your portal to all things service! Whether you need to order parts or register your warranty, Core Connect is the most effective way to get what you need fast and keep your facility operating smoothly. OFFERS 24-HOUR SELF SERVICE ACCESS TO: •... - Page 24 PART NUMBER 620-9131, REV B All rights reserved. Star Trac, the Star Trac logo and StairMaster are registered trademarks of Core Health & Fitness, LLC. Schwinn and Nautilus are registered trademarks of Nautilus Inc. used under license to Core Health & Fitness LLC. Throwdown is a registered trademark of Throwdown Industries, LLC.
