Star Trac StairMaster Owner's Manual

Core health & fitness personal viewing screen
Hide thumbs
Table of Contents

Advertisement

Quick Links

700 - 0351
C
H
F
ore
ealth &
P
V
ERSONAL
IEWING
O
M
WNER'S
ANUAL
ITNESS
S
CREEN
Installation Notice
Instant Channel Programming Feature
Complete the Signal / Power Connections and
Press 0001 to Begin Channel Programming Scan
15.6 NTSC / ATSC / QAM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the StairMaster and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Star Trac StairMaster

Summary of Contents for Star Trac StairMaster

  • Page 1 700 - 0351 ealth & ITNESS ERSONAL IEWING CREEN WNER’S ANUAL Installation Notice Instant Channel Programming Feature Complete the Signal / Power Connections and Press 0001 to Begin Channel Programming Scan 15.6 NTSC / ATSC / QAM...

  • Page 3: Table Of Contents

    CONTENTS page(s) page GENERAL SAFETY and CARE FCC Statement…………………………………. In the Box……………………………………..1 Connection Identification 2 Main Setup and Operation 1 Menu Operation......3 Channel Menu Air/Cable..….....………… Auto Scan.…......…. Show/Hide.......…... DTV Signal......… 4 Picture Menu Picture Mode…....……….. 2 Color Mode…....…….. 8 Aspect Ratio……....………..

  • Page 4: General Safety And Care

    GENERAL SAFETY and CARE Thank you for your purchase of the Core Health & Fitness personal viewing screen. This product has been designed specifically for use in the health & fitness industry, ensuring maximum performance and longevity in the harsh fitness club environment. Properly cared for, this product will provide years of high-quality entertainment.

  • Page 5: Fcc Statement

    Important Safety Instructions Before you begin, read all warnings. CAUTION!   RISK OF ELECTRICAL SHOCK Do not attempt to disassemble, open or otherwise service the product. There are no user-serviceable parts inside.       Do not expose unit to liquid, rain, excessive moisture  ...

  • Page 6: In The Box

    IN THE BOX ... 1) ST156TV2-NAQ2 Personal Viewing Screen 2) Manual 1. CONNECTION IDENTIFICATION DC Power In. 2.5mm DC jack RF Signal Input AUX TV Controller Cable port. RJ45 jack AUX CableSat port. RJ45 Jack. AUX Audio Output. 3.5mm stereo jack Firmware Download USB jack HDMI Port 2.

  • Page 7: Channel Menu

    3. CHANNEL MENU CHANNEL MENU contains 4 sub-menu presets (Air/Cable, Auto Scan, Show/Hide, DTV Signal) 3.1 Air / Cable Enter MENU 1. Use VOLUME ▲ ▼ keys to select Channel. 2. Use CHANNEL ▲ ▼ keys to select Air/Cable. Air/Cable Cable 3.

  • Page 8: Show/Hide

    3.3 Show/Hide Enter MENU 1. Use VOLUME  keys to select Channel. 2. Use CHANNEL  keys to select Show/Hide. Air/Cable 3. Push CC key. Auto Scan Show/Hide DTV Signal Bad Channel Enter MENU Show/Hide 1. Use CHANNEL  keys to select Channel. 2.

  • Page 9: Picture Menu

    4. PICTURE MENU PICTURE MENU contains 3 sub-menu presets (Picture Mode, Color Mode, Aspect Ratio) 4.1 Picture Mode Enter MENU 1. Use VOLUME  keys to select Picture. 2. Use CHANNEL  keys to select Picture Mode. Picture Mode Personal 3.

  • Page 10: Picture Mode

    Color Mode contains 3 video presets(Normal, Warm, Cool) Color Mode Normal Color Mode Warm Color Mode Cool R133 R127 R133 G130 G118 G130 B123 B123 MENU MENU MENU 4.3 Aspect Ratio Enter MENU 1. Use VOLUME  keys to select Picture. 2.

  • Page 11: Audio Menu

    5. AUDIO MENU AUDIO MENU contains 5 sub-menu presets (Equalizer, MTS Stereo, Audio Language, SurroundSound, AVC ) 5.1 Equalizer Enter MENU 1. Use VOLUME  keys to select Audio. 2. Use CHANNEL  keys to select Equalizer. Equalizer Personal 3. Push CC key. MTS STEREO Audio Language Enlish 4.
  • Page 12 5.2 Audio Language Enter MENU 1. Use VOLUME  keys to select Audio. Equalizer MTS STEREO 2. Use CHANNEL  keys to select Audio Language. Audio Language Enlish 3. Push CC key. Surround Sound AVC On Audio Audio Language contains 3 Language presets(English, French, Spanish) Audio Language supports digital broadcasting audio as digital broadcasting include several kinds of audio.
  • Page 13 5.4 AVC Enter MENU 1. Use VOLUME  keys to select Audio. 2. Use CHANNEL  keys to select AVC. Equalizer MTS STEREO 3. Push CC key to enter/change setting(ON or OFF). Audio Language Enlish SurroundSound AVC(Auto Volume Control) function is the ability to AVC On Audio automatically adjust volume level.

  • Page 14: Time Menu

    6. TIME MENU TIME MENU contains 6 sub-menu presets (Sleep Timer, Time Zone, DST, Time Format, Auto Sync, Clock) 6.1 Sleep Timer Enter MENU 1. Use VOLUME  keys to select Time. 2. Use CHANNEL  keys to select Sleep Timer. 3.

  • Page 15: Time Format

    6.3 Time Format Enter MENU 1. Use VOLUME  keys to select Time. 2. Use CHANNEL  keys to select Time Format. Sleep Timer 3. Push CC key to enter/change setting(12-Hour or 24- Time Zone Hour). DST Off Time Format 24-hour Time Auto Sync Clock 2015/1/26 18:3...

  • Page 16: Clock

    6.6 Clock Enter MENU 1. Use VOLUME  keys to select Time. 2. Use CHANNEL  keys to select Clock. Sleep Timer 3. Push CC key. Time Zone 4. Use CHANNEL  keys to select sub menu. 5. Use VOLUME  keys to adjust time. Time Format Time Auto Sync...

  • Page 17: Transparent

    7. SETUP MENU SETUP MENU contains 5 sub-menu presets (Menu Language, Transparent, Close Caption, Restore Default, USB Update) 7.1 Menu Language Enter MENU 1. Use VOLUME  keys to select Setup. Menu Language English 2. Use CHANNEL  keys to select Menu Language. Transparent 3.
  • Page 18 Transparent contains 5 presets(0, 25, 50, 75, 100%) Transparent 25 % 50 % 75 % 100 % MENU 7.3 Close Caption Enter MENU 1. Use VOLUME  keys to select Setup. 2. Use CHANNEL  keys to select Close Caption. Menu Language 3.

  • Page 19: Restore Default

    7.4 Restore Default Enter MENU 1. Use VOLUME  keys to select Setup. 2. Use CHANNEL  keys to select Restore Default. Menu Language 3. Push CC key. Transparent 4. Use VOLUME  keys to select Yes. Closed Caption Restore Default Setup USB Update Are you sure ?
  • Page 20 8. LOCK MENU LOCK MENU contains 6 sub-menu presets (Change Password, System Lock, Input Block, US, CANADA, Unrated) Enter LOCK MENU Enter Password “0000” on the number keypad. (Factory set password is “0000”) Enter Password _ _ _ _ Lock 8.1 Change Password Enter MENU 1.

  • Page 21: System Lock

    8.2 System Lock Enter MENU 1. Use VOLUME  keys to select Lock. 2. Use CHANNEL  keys to select System Lock. Change Password 3. Push CC key to enter/change setting(On or Off). System Lock Off Input Block Lock Canada RRTSetting ResetRRT Unrated...
  • Page 22 8.4 US Enter MENU 1. Use VOLUME  keys to select Lock. 2. Use CHANNEL  keys to select US. Change Password 3. Push CC key. System Lock On Input Block Lock Canada RRTSetting ResetRRT Unrated Enter SUB-MENU Page 1. Use CHANNEL  keys to select sub-menu. 2.
  • Page 23 8.5 CANADA Enter MENU 1. Use VOLUME  keys to select Lock. 2. Use CHANNEL  keys to select CANADA. Change Password 3. Push CC key. System Lock On Input Block Enter SUB-MENU Lock Canada 1. Use CHANNEL  keys to select. RRTSetting ResetRRT Unrated...
  • Page 24 9. CUSTOM FEATURES – ACCESS To enter CUSTOM FEATURES menu Custom Features 1. Enter the code “0003” on the number keypad 2. CUSTOM FEATURES menu (OSD) will appear Detect Vibration • Detect Vibration • Auto Power On Chanel Default Time •...
  • Page 25 Exclusive feature works with in-club private TV networks including ClubCom™ and Digital Signage systems. Custom Features When turned on the TV will automatically go the club promotional channel.The user cannot change the channel Detect Vibration until the promotional programming has ended. The TV then Chanel Default Time changes to the secondary club “Home Channel”...
  • Page 26 Used to change the TV POWER ON from factory setting Custom Features OFF. Upon being energized from a NO POWER state the TV will automatically turn on Detect Vibration Chanel Default Time In CUSTOM FEATURES menu Chanel Default 1. Press CHANNEL  keys to select AUTO POWER ON Auto Default 2.

  • Page 27: Assembly Drawing

    10. ASSEMBLY DRAWING SCREW PH M5 X 8 (BLACK) ROHS 4PCS• SCREW PH TAP 4.0 X 12 (BLACK) ROHS 8PCS• February, 2016(Version 2) ERSONAL IEWING CREEN WNER’S UIDE...

  • Page 28: Contact Information

    Contact Information 4400 NE 77th Avenue, Suite 300 Vancouver, WA 98662 Telephone: (888) 678-2476...
