  • Page 1 CORE HEALTH & FITNESS 8UB UPRIGHT BIKE OWNER'S MANUAL...
  • Page 2: Table Of Contents

    ASSEMBLY ........................5 ................5 REQUIRED TOOLS ASSEMBLY HARDWARE ................5 ASSEMBLY ..............6 FIRST TIME SETUP ..............9 OPERATION LED CONSOLES ........................10 MAINTENANCE MODE ..............12 MAINTENANCE ........................16 REPLACEMENT PARTS ........................17 9-8160-XXXXP0 - 8UB ..............17 SUPPORT & SERVICE ........................21 Page 2...
  • Page 3: Important Safety Instructions

    Do not exceed the maximum allowable weight limit of: WARNING: • 8UB - 350 lbs. / 159 kg. to reduce the risk of burns, fire, electric shock, or injury to persons Statement of Purpose: The exercise bike is a machine that simulates the movements A machine should never be left unattended when plugged in.
  • Page 4: Important Label Locations

    050-5990 050-5937 RESULT IN SERIOUS INJURY. 1. As with all exercise equipment or programs, LABEL, STAR TRAC, 191mm X consult a physician prior to use and stop KEYPAD, NAV BAR, LED DISPLAYS if you feel faint, dizzy or exhausted. 2. Inspect equipment before each use.
  • Page 5: Assembly

    ASSEMBLY REQUIRED TOOLS • Torque Wrench • 10mm Socket • Ratchet Wrench • 4mm, 6mm Allen Socket • #2 Phillips Screwdriver PARTS INCLUDED IN THE BOX: Description 718-1099 SADDLE, UPRIGHT BIKE 740-2034 ASSY, SEAT POST, SPORT, UB 718-6359-XX ASSY, BASE FRAME, 8-UB, BLK 718-6358 KIT, HARDWARE, S-UB, GEN 2, BLK 620-9093...
  • Page 6: Assembly

    ASSEMBLY Use a Phillips screwdriver to remove the 3 M5 x 35mm screws 110-4480 securing the machine cover 020-4472 to the mast, then remove the cover. (See Fig. 5) 020-4475 110-4480 020-4453 718-6350-XX 740-9313-XX Fig. 5 120-3547 Route the cable bundle through the beauty ring 740-8313-XX 110-3676 740-4593 and up through the mast 718-6350-XX, then install the mast...
  • Page 7 Adjust the front and rear leveling feet to stabilize the unit. 718-5627-XX Fig. 8 Unpackage the console and firmly pull the rear console cover off from the bottom. 10. Place the front of the console against the console weldment, angled forward. Make sure the bottom plastic of the console is below the wireless phone charger lip.
  • Page 8 11. Drape all wires from the base out the back of the mast weldment prior to installing the console. 12. Use a 10mm socket to secure the console to frame weldment with four screws 110-4447 as shown in Fig. 11. TORQUE TO 7.4-11 ft-lbs (10-15 Nm) If installing a PVS kit or 800/900 MHz controller, please refer to the...
  • Page 9: First Time Setup

    “model” is shown, then press the enter key select the model sub menu. Use the Level keys to choose “8RB/8UB”, then press enter to save the selection. Fig. 12 CONNECT WIFI Option 1 (Recommended): Alter facility SSID to match information built into LED display.
  • Page 10: Operation Led Consoles

    OPERATION LED CONSOLES USING THE CONSOLE QUICK START Key Enables manual operation using a default weight, SPEED and a default time limit. NOTE: Default time and weight are adjustable through Maintenance Mode. STOP Button Press the STOP button to enter pause mode. Workout will be suspended and a countdown timer will begin counting down from 2 minutes.
  • Page 11 Display Measurements Message Window The top display window includes several measures: TIME Current total workout time DISTANCE Total distance traveled in mile or HEART RATE Current HR in beats per minute, if available CALORIES Current total calories Progress Window & Track Shows a graphic representation of elevation Pace (TR only) during a program.
  • Page 12: Maintenance Mode

    MAINTENANCE MODE Maintenance Mode allows access to service and diagnostic information, as well as provides the ability to adjust certain program default parameters. To enter Maintenance Mode: 1. Press and hold the 1, 2 on the left keypad and the 8 key on the right keypad together. 2.
  • Page 13 A complete list of the items that you may display and change in Maintenance Mode: Highest Highest Item Lowest Value Default Notes Item Lowest Value Default Notes Value Value SYSTEM CALIBRATION DISP V0.3.1 (1) SPD CAL 00.09 (02) ELV CAL Elevation calibration function V2.3.5 EXIT...
  • Page 14 FCC INFORMATION & INDUSTRY CANADA WARNING FCC Warning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Text Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 15 (ii) for devices with detachable antenna(s), the maximum antenna gain permitted for devices in the bands 5250- 5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with the e.i.r.p. limit; pour les dispositifs munis d’antennes amovibles, le gain maximal d’antenne permis pour les dispositifs utilisant les bandes de 5 250 à...
  • Page 16: Maintenance

    MAINTENANCE TOOLS Working on this product will require basic and/or sometimes specialty tools based on the type of service that will be performed at any time. To assist, we recommend having the tools listed available when performing maintenance. • Metric Allen Key Set •...
  • Page 17: Replacement Parts

    SLEEVE, SEAT POST, SPORT UB 050-2215 LABEL, GENERAL WARNING, E-BTS 740-4593 Screw, Set, M8x1.25, 40MM, CPS, HK, AS, ECB 050-5990 LABEL, STAR TRAC, 191mm X 45mm, CR-BLK 740-7187 Screw, M6x1.0, 10mm, BHC, HE, SS 110-3164 SCREW, M4x0.7x16L,PHT,PH,SS 740-7553 BEARING, 6005 SERIES, 25x47x12, 2RS 110-3167 SCREW, M4x0.7, 64mm,PHT,PH,CS,ZI...
  • Page 18 220-0348 220-0350 220-0351 050-2051 220-0349 220-0354 220-0348 718-6358 718-5067 740-8204 110-3164 721-1134 110-3164 220-0349 Fig. 18 Cables and Hardware Kit Fig. 19 Connector 740-8145 740-9257 110-3717 718-5646 718-5268 718-5267 718-5266 731-0374 740-2036 740-4593 050-2215 718-6360 140-3250 718-5261-01 740-7916 110-3469 718-5277 731-0373 740-7553 130-1693...
  • Page 19 718-6350-XX 718-6346 220-0354 260-0984 718-6351 720-5319 110-3171 120-3246 718-5533 170-0729 720-5318 720-5317 Fig. 22 Generator Fig. 23 Handlebars and Cupholders 110-3259 140-3272 120-3252 120-3251 740-9572 721-1176 718-5067 110-3230 110-3177 140-3248 220-0348 220-0350 110-3164 260-0984 140-3243 Fig. 24 Idler Fig. 25 Lower Board and Battery Page 19...
  • Page 20 718-6350-XX 701-0558 740-9313-XX 110-3671 120-3547 110-3981 110-3676 110-3764 740-4593 718-6350-XX Fig. 26 Neck Hardware Fig. 27 Neck 718-1099 740-2034 110-4503 740-2036 120-3257 740-7898 718-6360 110-3164 718-5627-XX 718-5333-XX 740-8006 740-8007 740-7187 Fig. 28 Seat Post Fig. 29 Stabilizers Page 20...
  • Page 21: Support & Service

    SUPPORT & SERVICE CORE CONNECT Core Connect is your portal to all things service! Whether you need to order parts or register your warranty, Core Connect is the most effective way to get what you need fast and keep your facility operating smoothly. OFFERS 24-HOUR SELF SERVICE ACCESS TO: •...
  • Page 22 THIS PAGE INTENTIONALLY BLANK Page 22...
  • Page 23 THIS PAGE INTENTIONALLY BLANK Page 23...
  • Page 24 PART NUMBER 620-9093, REV D All rights reserved. Star Trac, the Star Trac logo and StairMaster are registered trademarks of Core Health & Fitness, LLC. Schwinn and Nautilus are registered trademarks of Nautilus Inc. used under license to Core Health & Fitness LLC. Throwdown is a registered trademark of Throwdown Industries, LLC.
