Star Trac 8CT Installation Checklist

Use the checklist below to ensure proper installation of the 8CT CrossTrainer:
All parts and hardware from packaging are accounted for. This machine is designed to be self-
powered. An AC adaptor is not included with the base. Some configurations may require external
power. An AC adaptor will be included with those configuration components. Reference document
#637-8485 for configuration information.
Ensure all screws are tightened and torqued to their specified values.
Ensure that drive belt, generator, and main drive pulley are all aligned with each other and that
mounting hardware (including set screws on pillow blocks and jack screws adjacent to pillow blocks) is
tight.
Verify that there is no noise/knocking/etc coming from the wheels under the pedals during use (be
sure to stand on the pedals while testing for this to ensure that there is user weight on the system).
Verify upper body arms are properly mounted/secured and move freely along the entire range of
motion. Use a manual screwdriver to place the elbow covers on the CT arms. DO NOT USE A POWER
DRILL
Verify upper neck is properly mounted and secured. Using all four M8 allen bolts with M8 washers. SET
SCREW MUST BE INSTALLED AND TOURQUED TO 8-10LBS-FT.
Make sure the display mounting bracket and back cover are properly mounted and secured.
All cables and harnesses are properly plugged into their respective connectors and are free from pinch
points when securing the console to the back console shroud.
The front and back display plastics/covers are properly installed and secured.
Ensure the console model (MDL) is set to the proper machine type:
o PRO CT = Cross Trainer
Verify Wall Power (Wall PW) is set to properly reflect if the machine is plugged in:
o OFF = SELF PW
o ON = PLUG IN 12V ADAPTOR
Test the heart rate in the maintenance mode by engaging the "heart rate test" and using the hand
grips and polar strap
Use unit in active program to test resistance and overall movement under load
Verify the battery voltage (BATT VLT) to be at least 6.2v within the maintenance mode.
Adjust the leveling feet to ensure the unit is stable and leveled.
Once powered up, all features of the unit function properly.
Check the fans for proper function
CORE HEALTH AND FITNESS

8CT Installation Checklist

8CT CrossTrainer
Page 1 of 2
Assembly & Setup
637-4318 Rev: B
