Summary of Contents for Star Trac 8-TRx
- Page 1 Core Health & Fitness Star Trac 8-TRx ASSEMBLY MANUAL...
-
Page 2: Product Spotlight
PRODUCT SPOTLIGHT 9-9251 - 110V, 18AMP 9-9252 - 220V, UL/FCC 9-9254 - 220V, 10AMP. CE 9-9201 - 110V, 18AMP, CSA/UL/FCC 9-9202 - 220V, UL 9-9204 - 220V, CE 8-TRx Overall Weight Width Length Height Max User Weight 475 lbs (167.5 kg) 38.6 in (98 cm) - Page 3 Description 701-0002-XX RAIL, SIDE, LT, E-TRx 701-0003-XX RAIL, SIDE, RT, E-TRx 020-7528 GROMMET, HANDRAIL, LEFT, E-TRX, TEARDROP 020-7527 GROMMET, HANDRAIL, RIGHT, E-TRX, TEARDROP 110-3416 SCREW, 5/16-18 X 1, SHC, HE, AS, BO, NP WASHER, LOCK, SPLIT, 0.58 OD, 0.32 ID, 0.078 120-0496 THK, CS, ZP WASHER, 5/16 SAE FLAT, 11/16”...
- Page 4 Use a 1/4” allen key to install the left side rail (701-0002-XX) to the frame using three (3) pieces each of the 5/16” x 1” socket head cap screw (110-3416), 5/16” split lock washer (120-0496), and 5/16” fl at washer (120-0490). Once the handrail is installed, slide the left side handrail grommet (020-7528) onto the rail - be careful of orientation of the grommet.
- Page 5 Install the upper handrail assembly (715-4137- XX) onto the mast and the left and right rails, then use 5/32” allen key to secure the upper handrail to the rails using four (4) pieces of the 1/4” x 3/8” button head cap screw (110-0506). Secure the upper handrail to the mast using four (4) pieces each of the M8 x 16mm button head cap screw (740-4588) and M8 fl at washer (731-...
- Page 6 Use a #2 phillips screwdriver to secure the back console shroud (020-7460-XX) to the console weldment using ten (10) pieces each of the #8-18 x 3/4” screw (110-3402) and M4 washer (120- 3307). Refer to the documentation contained inside the console box in order to connect the console to the unit.
-
Page 7: Support And Service
SUPPORT AND SERVICE The Support website provides a wealth of resources to help you get the best experience from your unit. It is important to check the website periodically for Owner’s Manual and Installation Instruc- tions, Service Bulletins, and other information. The resources include: •... - Page 8 © 2019 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8379, REV C...
