- Page 2 H•KING --- , SI<\' IIJlllJEII This plane is guaranteed to be free from defects in material and workmanship at the date of purchase. It does not cover any damage caused by use or modification. The warranty does not extend beyond the product itself and is limited only to the original cost. By the act of controlling this product, the user accepts all resulting liability for damage caused by the final product.
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS 1. Please read this manual carefully and follow the instructions before you use this product. 2. This airplane is not a toy but due to having installed the ORX stabilization system it is suitable for pilots with low experience. However, if you do fall into this category then we recommend you enlist the help of an experienced RIC pilot to give you a hand with the initial flights. - Page 4 H•KING • Fuselage with pre-installed motor, propeller, ESC and seNOS • Main landing gear • Main wing with pre-Installed seNOS • Bombs, rockets and smoke canister dummies are all skl l lftJly painted • Horizontal stabiNzer • Hardware and plastiC accessorieS pael< \ioos •...
- Page 5 i'- I Sl<Y .,.,.- 1i,11111-:1i ■ +ii41ilcttlf®li 19iM1Ff 1. Insert the main landing gear into the slots in the wing and secure using the 2 x 8mm self tapping screws provided. 2. Slide the horizontal stabilizer through the slot in the rear of the fuselage. Oleck that it is central then carefully glue into place using a medium CA glue.
- Page 6 H•KING 3. Connect the elevator pushrod clevis to the outer hOle in the elevator control horn. Please ensure the safety keeper is slid into place after connecti n g. 4. Connect the aileron servo leads to the Y lead in the fuselage then attach the wing using the M4 x 45mm screw provided.
- Page 7 i'- I Sl<Y .,.,.- 1i,11111-:1i 5. Please note that the smoke cannisters are marked with "L" and "R" so please attach to the correct wing panel. 6. Glue the bomlets and smoke canister to the wing using a medium CA glue into the indents in the wing.
- Page 8 H•KING 7. Using a medium glue attach the · 4 cannons to the slots in the leading edge of the wlngs 8. The assembly of your A-1 Skyrai d er iS now complete.
- Page 9 i@fiMl llfiFl'Jh' W' This is between 55-62mm from the wing leading edge. For initial flights have the C of G nearer the forward mark to improve the stability in pitch. As you get used to the model you can move it back a little to make it more aerobatic if you wish.
- Page 10 H•KING system flight stabilisation Features: • Integrated with a 32bit MCU and a 6 axis digital gyro for ultra fast flight control response. • The ORX stabilisation device is tuned specifically to a particular model for the best flying performance. •...
- Page 11 We hope you enjoy flying your H-KING A-7 Skyraider and if you haven't already tried out the others in our range then we recommend you visit our website at www.hobbyking.com and take a look at our...
- Page 12 H•KING _ _j a .,. No:top02601 No:top02603 No:top02605 Fuselage(white) Main wing(white) Horizontal wing(white) 00 00 No:top02616 No:top02607 No;top02609 Main landing gear(white) Hub(white) Propeller(white) No:top40103 Motor (DST-820)
- Page 13 i'- I Sl<Y .,.,.- 1i,11111-:1i Turnigy nano-tech 850mah 3S Turnigy B0OmAh 3S 2S~40C Lipo Pack 20C Lipo Pack SKU: NBS0.3S.25 SKU: TB00.3S.20 ZIPPY Flightmax 800mAh 3S1P Turnigy Nano-Tech 850mAh 3S 20C Lipo Pack J0C Lipo Pack SKU: Z8003S20C SKU:9210000273-0...
- Page 14 ''· Sl<Y H•KING 11,11111-:11 11 i II I Q tli,111 I I ,Pf Trouble Possible Reason Action Motor doesn't work, but there are The ESC throttle calibration has not audible tones signalling the number Set up the ESC throttle calibration. been set of cells.
