HEALTH
Non-Locking Caster Replacement
1.
Pull lever to recline chair.
2.
Detach velcro strip and move cover to
gain access.
3.
Use a 15/16" deepwell socket to remove
the nut that is securing the caster.
4.
Remove the caster.
5.
Reverse procedure to install
replacement caster.
NON-LOCKING CASTER
1
3
4
5
2
939599290 Rev C
Page 2 of 6
