KWM Gutterman IronMan Operating And Maintenance Troubleshooting Manual page 41

STEP 12: MOVE THE THREE FACE BOX ASSEMBLY STATIONS. (SEE PG. 37)
Pull the retractable pin that is located at the top of each station assembly.
•
Lower the face roller assembly down to the 5" gutter position and release pin.
•
Repeat this step for each of the face box assemblies.
•
STEP 13: REMOVE THE 6" INSIDE BOX ROLLER BAR ASSEMBLY. (SEE PG. 37)
To remove the 6" inside box roller bar assembly, remove the two RED station F-screws on the top of the box.
•
Place this assembly to the side.
•
STEP 14: INSTALL THE 5" INSIDE BOX ROLLER BAR ASSEMBLY. (SEE PG. 37)
Remove the 5" inside box roller bar assembly from the storage location; this assembly is labeled as 5".
•
Install the 5" inside box roller bar assembly in the lip box, replace the two RED station F-SCREWS and tighten.
•
The tall rollers located in the #1 station and the #2 station.
•
The short rollers located in the #3 station and the #4 station.
STEP 15: STORE 6" INSIDE BOX ROLLER BAR ASSEMBLY. (SEE PG. 37)
Install the 6" inside box roller bar assembly from the storage location.
•
STEP 16: MOVE THE SIX OUTSIDE BOX BOTTOM ROLLERS. (SEE PG. 37)
Pull the retractable pin and raise the bottom portion of the outside roller up to the 5" position.
•
Release the retractable pin.
•
Repeat this step for each of the lip box stations.
•
STEP 17: MOVE LIP BOX ASSEMBLY. (SEE PG. 37)
Loosen the two MOUNTING BOLTS on the ENTRANCE MOUNT ASSEMBLY. (BLACK)
•
Loosen the two MOUNTING BOLTS on the EXIT MOUNTING ASSEMBLY. (GREEN)
•
Move the lip box in and down on the box frame mounts.
•
Tighten mounting bolts.
•
STEP 18: REPLACE #1-4 COVERS. (SEE PG. 34)
Turn the cover screws ¼ turn clockwise to fasten.
•
STEP 19: MOVE UPRIGHT BASE-PLATE. (SEE PG. 10)
Remove Coil Spool from Upright Assembly
•
Rotate the upright to access the two bolts on the face side.
•
Loosen the four L-SCREWS as shown.
•
Slide the upright base-plate to the 5" position.
•
Tighten the screws.
•
STEP 20: REPLACE THE 6" SPOOL ASSEMBLY WITH 5" SPOOL ASSEMBLY. (SEE PG. 10)
Remove the 6" spool assembly
•
Load the 5" gutter material on Spool Assembly.
•
Place loaded spool onto upright assembly using an approved lifting device.
•
NOTE: Pins must be reinstalled in holes stamped for the 5" position.
•
CAUTION: Spool must line up with the entrance guides.
