Upright Turnstile Assembly; Spool Assembly And Loading Coil - KWM Gutterman IronMan Operating And Maintenance Troubleshooting Manual

The IRONMAN TURNSTILE UPRIGHT is a modular turnstile support used to hold coil.
Your machine may have up to three uprights.
ONE TURNSTILE UPRIGHT ASSEMBLY CONSISTS OF: (SEE PG. 11)
TURNSTILE UPRIGHT (1)
BASE PLATE (1)
TURNSTILE LOCKING PIN (1)
TO ROTATE TURNSTILE FOR TWO-SIDED COIL:
1. Disengage the TURNSTILE LOCKING PIN.
2. Rotate TURNSTILE 180 degrees.
3. Re-engage the TURNSTILE LOCKING PIN.

SPOOL ASSEMBLY AND LOADING COIL

ONE SPOOL ASSEMBLY CONSISTS OF: (SEE PG. 11)
SPOOL SHAFT (1)
TO LOAD COIL ONTO SPOOL ASSEMBLY:
1. Place the empty spool assembly on the ground or on a flat surface.
2. Remove one of the 5/16" quick release pins.
3. Slide the spool half off of the ¼" spool shaft.
4. Insert the spool shaft through the center of the coil.
5. Replace spool half on the spool shaft, and reinstall the 5/16" quick release pin.
6. The spool assembly and coil are now ready to load onto the upright.
NOTE: The spool assembly is adjustable to accept both 5" gutter material (11 ¾" – 12") and 6" gutter material (15").
PLACING SPOOL & COIL IN THE UPRIGHT:
Use an approved lifting device in the designated spool lifting area to position the spool assembly into the turnstile upright.
(IMPORTANT! – Please read PRECAUTIONS)
PRECAUTIONS:
Make sure loading area is clean and clear of debris.
Make sure Turnstile Locking Pin is securely installed.
Always wear protective footwear when handling coil.
Never load coil with the brake in closed position.
Never operate machine without first checking brake & pin positions.
Never transport machine without locking brake in closed position.
SECTION: 7
SPOOL UPRIGHT SUPPORTS
TENSION BRAKE (2)
THUMB SCREW (2)
SAFETY PIN (2)
SECTION: 8
SPOOL HALF (1)
11
5/16" QUICK RELEASE PIN (2)
