Use #3 DRIVE FORMING ROLLER and SWING SHAFT ASSEMBLY as a
secondary option to acquire the same results. (SEE PG. 20)
NOTE: Loosen LOCKING BOLT K prior to adjusting the top #3 DRIVE FORMING ASSEMBLY.
** CAUTION: Over-adjustment will cause OPPOSITE reaction. **
A.) To correct for DOWN and AWAY from the fascia board:
Add pressure to the face side of the top #3 DRIVE FORMING ROLLER.
i. Turn locknut on ADJUSTMENT BOLT I counter-clockwise to loosen.
ii. Turn ADJUSTMENT BOLT I clockwise 1/64 of a turn.
iii. Add pressure to the SWING SHAFT (BLUE station).
iv. Turn LOCKING BOLT E (2 places) counter-clockwise to loosen.
v. Turn ADJUSTMENT BOLT F clockwise 1/64 of a turn.
vi. Retighten all locking bolts/nuts.
B.) To correct for UP and INTO the fascia board:
Relieve pressure from the face side of the top #3 DRIVE FORMING ROLLER.
i. Turn locknut on ADJUSTMENT BOLT I counter-clockwise to loosen.
ii. Turn ADJUSTMENT BOLT I counter-clockwise 1/64 of a turn.
iii. Relieve pressure to the SWING SHAFT (BLUE station).
iv. Turn LOCKING BOLTS E clockwise to loosen.
v. Turn ADJUSTMENT BOLT F counter-clockwise 1/64 of a turn.
vi. Retighten all locking bolts/nuts.
NOTE: After adjustment is made, run an 8' section of gutter to inspect.
If more adjustment is needed, repeat procedure.
3. ADJUSTING THE WIDTH OF THE GUTTER
If gutter is too wide or narrow between lines #3 and #9: (SEE PG. 42)
1. Check lines #6 & #7 for being at a 90-degree angle to the bottom. (SEE PG. 21)
A.) If less than a 90-degree angle is present: Add pressure to bell wheel.
i. Turn LOCKING BOLT A and PIVOT BOLT B counter-clockwise to loosen.
ii. Turn ADJUSTMENT BOLT B clockwise a 1/16 of a turn.
B.) If more than a 90-degree angle is present: Relieve pressure to bell wheel.
i. Turn LOCKING BOLT A and PIVOT BOLT B counter-clockwise to loosen.
ii. Turning ADJUSTMENT BOLT B counter-clockwise a 1/16 of a turn.
2. If #6 and #7 are square to the bottom and the gutter is too wide or narrow. (SEE PG. 18)
A.) If gutter is too wide: Move EXIT BOX MOUNT towards the back of gutter.
i. Loosen MOUNTING BOLTS (K)
ii. Loosen LOCKING NUT (L-2)
iii. Turn ADJUSTMENT BOLT (M-2) clockwise 1/16 of a turn.
iv. Tighten MOUNTING BOLTS (K) and LOCKING NUT (L-2)
B.) If gutter is too narrow: Move EXIT BOX MOUNT away from the back of gutter.
i. Loosen MOUNTING BOLTS (K)
ii. Loosen LOCKING NUT (L-1)
iii. Turn ADJUSTMENT BOLT (M-1) clockwise 1/16 of a turn.
iv. Tighten MOUNTING BOLTS (K) and LOCKING NUT (L-1)
NOTE: After adjustment is made, run an 8' section of gutter to inspect.
If more adjustment is needed, repeat procedure.
