Operation

OneControl ® Control Panel
1. The control panel will operate various devices connected to the OneControl® system.
2.
Locate "OneControl® Control Panel" (Fig. 5).
3.
Pressing the "OneControl® Control Panel" (Fig. 5A) will open "OneControl® Applications".
4. Pressing the "Tank Monitor" icon (Fig. 6A) will allow you to access the tank monitor screen (Fig. 7).
NOTe: The indicator panel light will be depicted by the use of the tank; a gray line for the gray tank, a blue
line for the blue tank, etc.
NOTe: Only the tanks used and configured will be displayed on the screen.
NOTe: Battery voltage is also displayed on the monitor panel screen (Fig. 7A).
A
Rev: 06.12.19
Fig. 5
A
Fig. 6
Page 5
Fig. 7
A
