Resistor Pack

• White – Ground(-) connect to EMPTY (E) sensor
• Yellow – connect to LOW level (1/3) sensor
• Green – connect to MID level (2/3) sensor
• Red – connect to FULL level (F) sensor
• Pink – signal wire connects to "Tank" wire from monitor harness. This wire is connected to the proper
input wire on the panel harness.
NOTe: The sensors are connected to the yellow, green, and red wires on the sensor resistor pack (Fig. 4). The
tank sensor resistor pack connects to the tank sensor with an eyelet being screwed down onto the
sensor.
Rev: 06.12.19
Fig. 4
