Assemble the 2x 3mm Phillips
screws at the stand off locations.
If the standoff has been removed
as per step 5, do not screw at
the M.2 connector location.
Apply the thermal pad on-top of
the M.2 SSD
Stick the RTC backup battery in
its place
Note
Before placing the bottom cover,
make sure the U-shaped Boss is
on the side of the M.2
connectors
Screw the 4x Phillips enclosure
screw half way, enough to hold
the bottom cover in-place but not
too tight
Bring both side panels in place,
and hold them
Complete by tightening the
Phillips enclosure screws all the
way down, while holding the side
panels
Page 4
